Characteristics:
1. Low speed generator, use rare earth permanent magnet materials, strong overloading ability.
2. Use high-quality bearings, magnet and other components, the radiation heat is strong and demagnetization rate is low.
3. The body is made of high-quality steel pipes, have a good anti-corrosion treatment, prevent wind sand, prevent salt spray and other erosion.
4. With overcharge, over-discharge, exchange unloading and short-circuit protection, DC-constant voltage charging, run the simple, non-artificial unattended and special maintenance.
5. To install small occupancy area and on the geology require low, in the hills, the beach, river bank, desert terrain, etc. Can be installed under the conditions of use.
6. Generator sets operation stable, reliable quality, the design life of 25 years, an investment and long-term benefits.
CAT-30KW Wind Generator Technical Parameter
Item parameter
Blades diameter(m): 12.5
Material and quantity: 3 PCS Strenghthened form in one piece made by hand
Rated power(w): 30000
Max power(w): 35000
Annual power generation(kwh): 15000-45000
Rated rotor speed(r/min): 160
Start-up wind speed(m/s): 3
Working wind speed(m/s): 4-25
Rated wind speed(m/s): 8
Security wind speed(m/s): 50
Work voltage(v) AC260
Batteries voltage(v)/capacity(AH): 360V200AH 120PCS(30PCS in series and 4 groups in parallel)
Adjust method: Automatically yaw+Electromagnetic damping adjusting speed
Brake method: Manual and Automatic brade\security protection system
Generator type: Three phase and permanent magnet generator
Generator class of insulation: F
Host weight:
Guyed Tower Height/Weight(kg):
Free Stand Tower Height/Wei:
Whole system package volume(m3):
Noise level(dB): <65
Zibo CAT Wind Generator Co., Ltd. is a National high-tech enterprise specialized in research, development, marketing and sales of renewable energy products especially for wind power. The main products including Small and Medium wind generators, inverter & controller for photovoltaic system &wind system, solar and wind hybrid generators, solar and wind hybrid street light, wind-diesel hybrid system, wind-solar-diesel hybrid system. We provide project consulting, system design, technical support, and other services to the whole project process.
Company Located in Zibo City, China, Near 1 hour from Jinan airport, 3 hours from Qingdao port. Covering an area of 4000 square meters. CE certified, the company has a complete series of strict testing and quality guarantee methods for all of the products. The products has exported to numerous oversea markets: North America, UK, Ireland, India, Italy, France, etc; There is also a wide range of domestic application of these product on oil field, farmland, industry park, military camp, fishing farm and port warehouse as well.
