Pitch controlled wind turbine is a technical revolution in small and medium wind turbine industry. Through centifugal pitch controlled mechanism, it adjusts the blade angle according to the wind speed, to guarantee the wind rotor use efficiency at optimumcondition. Meanwhile, the wind rotor never overspeed. Thus the wind rotor use efficiency is high and more electricity generated.2kw, 5kw, 10kw 20kw, 30kw
pitch controlled wind turbine also available
| HY--5000W Technical Parameter |
| Rated power(kW) | 5 | Material of the blades | Fiberglass-Reinforced Plastics |
| Rated wind speed(m/s) | 11 | Speed regulation method | Adjustable-Pitch of blades |
| Startup wind speed(m/s) | 3 | Generator style | 3-phase AC PM |
| Working wind speed(m/s) | 4~25 | Tower height (m) | 8 |
| Survived wind speed(m/s) | 50 | Stop method | Sweepback
Adjustable-Pitch |
| Rated rotate speed (r/min) | 240 | Main machine weight(kg) | 340 |
| Rotor Diameter(m) | 5.6 | Guyed tower weight(kg) | 380 |
| Working voltage(v) | DC240V/AC220V | Freestanding tower weight (kg) | 600 |
Annual power generation
(KWH) | 7500/22500 |
Willgain Power Industry Co., Limited is specialized in manufacturing and supplying wind turbine and generatering system since 2008. We mainly supply horizontal/vertical axis wind turbine from 300W-500kw, horizontal/vertical permanent magnet generator from 300W-1000kw with various speed based on customer's requirements and Francis/Kaplan type hydro turbine system below and over 50kw.
Our partner manufacturers are committed to continuously improving our operations and meeting the needs of our customers through innovation and new product development. We work closely with them to optimize the performance and cost-effectiveness of their processes.
