1. 4kw fixed pitch yawing wind turbine advantage
Fixed pitch wind turbine 4kw including: 3 pcs FRB blades, nose cone, hub, generator with manual brake parts, nacelle, tail rod, tail vane.
Low/normal average wind speed wind turbine
Fixed pitch,auto yaw, auto brake, manual brake protection system.
Low cost, reliable and steady working system
Low start up wind speed 3m/s
Low noise level, provide noise drawing chart
High efficiency 3 phrase AC permanent magnet generator
Vacuum mould blades with protection film, long worklife span in sand wind condition
Wind turbine with antiseptic treatment, hot-galvanize tower. It can be work in sea side, island, lake...
tilting up tower is easy to installation for sample order; Hydraulic tower is easy to install for bulk order.
Guy wire tower cost is lower and easy to delivery.
We provide completely on grid system kit, off grid system kit, wind solar hybrid on/off grid system kit. Grid power and diesel generator as backup power
2. FD4-4kw wind turbine technical data:
Fixed pitch wind turbine Fd4-4kw, lower cost, easy installation and maintans, reliable working system.
On/off grid working system
high efficiency generator
Yaw system
provid system design, system design advise and relating technical support.
4kw wind turbine on/off-grid working system normal data:
Model: FD4-4kw
Rotor Diameter: 4m
Number of Blades: 3pcs
Material of Blades: Fibre glass expoxy
Cut-in wind speed: 3m/s
Working wind speed: 4-30m/s
Survival wind speed: 50m/s
Rated wind speed: 12m/s
Rated rotate speed: 280r/min
Rated output power: 4kw
Max output power: 5kw
Type of tower: Guy wire tower, tilting up tower, stand alone tower, lattice tower (optional)
Type of generator: Permanent-magnet 3 Phase AC
Speed regulation method: Yaw+auto brake
Working voltage: DC48V, DC120v, DC240V DC300V, DC500V optional
Operating Temperature: -40---+60
Tower height: 8m-15m
Wind turbine main body weight: 220kg
Measurement(CBM): 2
Life span: 15-20 years;
Warranty: 3 years (after installation).
__________________________________________
Note:
1. Tower type, tower height can be special requested;
2. working voltage can be special requested;
3.Ce,ccc,iso approved
4. For on-grid working system data, pls contract with us.
For output power curve, pls contact with us!
http://www.huayaturbine.com
3. Production Capacity: 200 sets per month
4. Main market: US, Canada, Australia, New Zealand, European...
5. Testing Machinery:
Generator platform test
Blade balance adjustment instrument
Blade weight center test platform
Turbine turn-to-turn test system
......
CE, ISO,IEC approved
6. Application
Home, farm, signal station, island, garden...
Qingdao Henryd Wind power Equipment Co., Ltd. is specialized small wind turbine generator manufacture in China. We own over 10 years practical experience in technical research, development and application of wind turbines. Also we have a strong r & d team to give our wind turbine tech supports. Our sales dept with many years experience in trading area will give you more supports.
We provide:
1)300w-30kw horizontal wind generator off-grid working system
1kw, 2kw,2.5kw 3kw, 5kw, 10kw, 20kw 25kw 30kw on-grid working system
2.)Vertical axis wind turbine 1kw 2kw,3kw 5kw
5-7 pcs stallout FRB blades.
3.) Variable pitch wind turbine 2kw 3kw 5kw 10kw 20kw 30kw 50kw 60kw
4.)2.2m-24m(diameter) frb, horizontal axis, 3 PCS aerofoil blades, past wind tunnel test, high efficiency.
5. )guy wire tower, independance tower, tilting up tower, hydraulic tower
