Characteristics:
1. Low speed generator, use rare earth permanent magnet materials, strong overloading ability.
2. Use high-quality bearings, magnet and other components, the radiation heat is strong and demagnetization rate is low.
3. The body is made of high-quality steel pipes, have a good anti-corrosion treatment, prevent wind sand, prevent salt spray and other erosion.
5. Rotary body part use a closed transmission slip ring, cable is not enwind.
4. With overcharge, over-discharge, exchange unloading and short-circuit protection, DC-constant voltage charging, run the simple, non-artificial unattended and special maintenance.
5. To install small occupancy area and on the geology require low, in the hills, the beach, river bank, desert terrain, etc. Can be installed under the conditions of use.
6. Generator sets operation stable, reliable quality, an investment and long-term benefits.
Item Parameter
Blades diameter(m) 5
Blade material and quantity 3 PCS Strenghthened form in one piece made by hand
Rated power(w) 3000
Max power(w) 3500
Annual power generation(kwh) 4500-13500
Rated rotor speed(r/min) 260
Start up wind speed(m/s) 3
Working wind speed(m/s) 4-25
Rated wind speed(m/s) 11
Security wind speed (m/s) 50
Working Voltage(v) AC160
Batteries Voltage(v)/Capacity(Ah) 220V150AH
Speedgoverning method Electromagnetic damping adjusting speed
Brake method Manual brade\security protection system
Generator Type Three phase and permanent magnet generator
Generator insulation F
Host weight
Guyed Tower Height/Weight(kg)
Free Stand Tower Height/Weight(kg)
Whole system package volume(m3)
Noise Level(dB) <65
