Gasoline Generator Set GHG3500
Features and benefits:
A new AVR (Automatic Voltage Regulator) delivers non-fluctuating power.
Powerful HD170FA gasoline engine.
Low oil pressure alert system shuts down the engine automatically.
New design control panel.
|
|
MODEL |
HG3500 |
|
|
Type |
Brush single-phase |
|
Generator |
Voltage Regulate |
AVR |
|
|
Frequency |
50/60Hz |
|
|
Rated Ac Output |
2.8/3.0KW |
|
|
Max Ac Output |
3.0/3.5KW |
|
|
Rated Ac Voltage |
220/120V |
|
|
Power Factor |
COSΦ =1.0 |
|
Gasoline |
Model |
HD170FA |
|
Engine |
Type |
OHV Forced Air-cooled, 4-Stroke |
|
|
Bore× Stroke |
1-70× 56mm |
|
|
Air cleaner |
Semi-dry double silent type |
|
|
Cooled way |
Air-cooled |
|
|
Displacement |
218ml |
|
|
Compression ratio |
8.5: 1 |
|
|
Max torque |
13/2500 N. m / rpm |
|
|
Ignition system |
Non-contact transistorized ignition(T. C. I) |
|
|
Spark plug gap |
0.7mm |
|
|
lubricating oil |
SF or Higher Grade |
|
|
lubricating oil capacity |
0.6L |
|
|
Lubrication system |
Pressure Splash |
|
|
Fuel consumption |
374(g/KW-hour) |
|
|
Power output |
7.0/3600(HP/ rpm) |
|
Generator |
Fuel |
Unleaded gasoline |
|
Set |
Starting system |
hand-operated |
|
|
Noise level |
67(7m)dB(A) |
|
|
Oil alarm |
No lube oil Auto stop safekeeping |
|
|
continuous operating |
13h |
|
|
Fuel capacity |
15L |
|
|
Front panel control system |
Two AC Socket-Ac-circuit one socket |
|
|
Dc-Output |
DC12V/8.3A customer optional |
|
|
BATTERY |
6-FM-15, 12V15Ah |
|
|
Dimension L× W× H |
600*450*460mm |
|
|
Gross/ Net weight |
47/45kg |
|
|
Unit(20FT) |
240 |
