Cummins diesel generator is a leading brand in genset fieldl with first-calss quality. The following is main features of Cummins engine diesel generator:
A. Four valves for each cylinder and direct fuel injection enhance the power and reduce fuel consumption.
B. Direct quench hardening of crankshaft and camshaft, with better reliablility and linger life.
C. Extremely low oil consumption.
D. Good quality cast iron and specially designed valve guide ensure sealing performance and durability.
Model
|
6LTAA8.9-G2
|
Standby Power(50Hz)
|
275KVA/220KW
|
Prime Power(50Hz)
|
250KVA/200KW
|
Voltage
|
230/400 V
|
Frequency
|
50Hz
|
Open type Dimension
|
2540*980*1670mm
|
Open type Weight
|
2200kg
|
Sales Promises
l We provide a full line of brand new and high quality products. Each and every unit is strictly factory tested.
l Warranty is according to our standard conditions: 12 months or 1000 running hours, subject to the earlier item
|
Diesel Generator Set Data
|
Voltage Regulation:
|
≥ ± 5%
|
Voltage Regulation, Stead State:
|
≤ ± 1%
|
Sudden Voltage Warp (100% Sudden Reduce):
|
≤ +25%
|
Sudden Voltage Warp (Sudden Increase):
|
≤ -20%
|
Voltage Stable Time (100% Sudden Reduce):
|
≤ 6S
|
Voltage Stable Time (Sudden Increase)
|
≤ 6S
|
Frequency Reduce:
|
0-5% adjustable
|
Frequency Regulation, Stead State:
|
≤ 1.5%
|
Frequency Waving:
|
≤ 0.8%
|
Sudden Frequency Warp (100% Sudden Reduce):
|
≤ +12%
|
Sudden Frequency Warp (Sudden Increase):
|
≤ -10%
|
Frequency Recovery Time (100% Sudden Reduce):
|
≤ 5S
|
Frequency Recovery Time (Sudden Increase):
|
≤ 5S
|
Diesel Engine Data
|
Manufacturer/Model
|
Cummins 6LTAA8.9-G2, 4-cycle
|
Air intake system
|
Turbocharged, Air/Air cooling
|
Fuel system
|
Cummins P7100 model fuel pump
|
Displacement
|
8.9 L
|
Cylinder arrangement
|
6 in line
|
Bore and Stroke
|
114*145 mm
|
Compression ratio
|
16.0: 1
|
Rated RPM
|
1500 rpm
|
Max. Standby Power
|
240KW/326HP
|
Governor type
|
Electronic
|
Exhaust gas flow
|
35 m3/min
|
Max intake Restriction
|
6.2 KPA
|
Fuel system 100%(Prime Power) Load
|
46 L/h
|
Total oil capacity
|
27.6 L
|
Oil Consumption
|
≤ 4 g/kw. h
|
Total Coolant Capacity
|
41 L
|
