Model: FD10-20kw & FD12-20kw
Rotor Diameter: 10m or 12m
Number of Blades: 3PCS
Material of Blades: Fibre glass expoxy
Cut-in wind speed: 3m/s
Working wind speed: 4-30m/s
Survival wind speed: 50m/s
Rated wind speed: 12m/s (FD12 rated wind speed is 9.8m/s)
Rated rotation speed: 170r/min (FD12 is 150rpm)
Rated output power: 20kw
Max output power: 30kw
Type of tower: Independence tower/Guy wire tower
Type of generator: Permanent-magnet 3 Phase AC
Speed regulation method: Yaw
Stop method: Manual brake/auto brake
Working voltage: DC500V
Tower height: 15m or special rquest
Wind turbine main body weight: 1300kg
Life span: 15 years
Warranty: 2 years
Working system: Off-grid working system
On-grid working system
You can take the whole system from us, also you can take any parts of the system from us.
For on-grid working system, we can provide wind turbine, on grid controller. We provide the generator actual test data, then you can get the inverter from local.
For more details, pls contract with us by e-mail.
Qingdao Henryd Wind power Equipment Co., Ltd. is specialized small wind turbine generator manufacture in China. We own over 10 years practical experience in technical research, development and application of wind turbines. Also we have a strong r & d team to give our wind turbine tech supports. Our sales dept with many years experience in trading area will give you more supports.
We provide:
1)300w-30kw horizontal wind generator off-grid working system
1kw, 2kw,2.5kw 3kw, 5kw, 10kw, 20kw 25kw 30kw on-grid working system
2.)Vertical axis wind turbine 1kw 2kw,3kw 5kw
5-7 pcs stallout FRB blades.
3.) Variable pitch wind turbine 2kw 3kw 5kw 10kw 20kw 30kw 50kw 60kw
4.)2.2m-24m(diameter) frb, horizontal axis, 3 PCS aerofoil blades, past wind tunnel test, high efficiency.
5. )guy wire tower, independance tower, tilting up tower, hydraulic tower
--factory direct sales--
Good price and higher quality, provide technical support more professional.
