Advantage:
1. Through the CE certification.
2. Rare earth permanent magnet materials
3. Professional magnetic circuit design
4. Constant voltage charging
5. Anti-corrosion
6. Low start-up wind speed
7. Maintenance free
8. Easy to install & operate
9. Suitable for family
10. Low vibration
11. High performance-price ratio
Item parameter
Blades diameter(m): 3.2
Material and quantity: 3 PCS Strenghthened form in one piece made by hand
Rated power(w): 1000
Max power(w): 1200
Annual power generation(kwh): 1500-4500
Rated rotor speed(r/min): 375
Start-up wind speed(m/s): 3
Working wind speed(m/s): 4-25
Rated wind speed(m/s): 11
Security wind speed(m/s): 50
Work voltage(v) AC36
Batteries voltage(v)/capacity(AH): 48V200AH
Adjust method: Electromagnetic damping adjusting speed
Brake method: Manul brake\Automatic security protection system
Generator type: Three phase and permanent magnet generator
Generator class of insulation: F
Noise level(dB): <65
Zibo CAT Wind Generator Co., Ltd. is a National high-tech enterprise specialized in research, development, marketing and sales of renewable energy products especially for wind power. The main products including Small and Medium wind generators, inverter & controller for photovoltaic system &wind system, solar and wind hybrid generators, solar and wind hybrid street light, wind-diesel hybrid system, wind-solar-diesel hybrid system. We provide project consulting, system design, technical support, and other services to the whole project process.
Company Located in Zibo City, China, Near 1 hour from Jinan airport, 3 hours from Qingdao port. Covering an area of 4000 square meters. CE certified, the company has a complete series of strict testing and quality guarantee methods for all of the products. The products has exported to numerous oversea markets: North America, UK, Ireland, India, Italy, France, etc; There is also a wide range of domestic application of these product on oil field, farmland, industry park, military camp, fishing farm and port warehouse as well.
