15W Portable solar energy home system
Patent NO.: ZL201120213080.0
15W solar power case
Detailed Product Description
1) Solar power case is small AC Power Supply System which is designed for the farmers, businessmen, etc.
15W Portable solar energy home system
Characteristics: The system has high conversion of silicon solar cell, high euphotic rate and mechanical strength, good resistance to climate, preventing wind, hail. Which can effectively resist corrosion of moisture and salt fog, . Conversion efficiency can be more than 15%, temperature range: - 25 to 80 degrees Celsius.
Appliance range: Electronic appliances such as mobilephone charging, notebook computers, lights, digital camera, video camera, TV, electric tools, music CD, DVD, electric power whose voltage is in 50Hz, 220V, Design and manufacture as the small AC/DC power supply system, for farmers in remote areas, and posts, fieldwork, small tourist camping It is the necessary perfect product in the portable office, fieldwork, and cutoff.
Operation:
1. When product is produced, the power switch is "OFF", turning "ON" when using.
2. Clicking " Light touch switch ", LED digital diode display "6. ", showing off and on. Meantime, AC220V DC12V output.
3. LED1 is "blue" when solar light charge for built-in battery.
4. LED2 is "green" when built-in battery working on a normal voltage, if turn red, "shows that built-in battery has a low working voltage.
5. LED3 is "red" when output works normally.
Technical parameters:
Solar panel: 18V /15W
Working voltage: 18V
Working current: 0.8A
Open-circuit voltage: 21.6V
Short-circuit current: 0.84A
Maximum system voltage: 1000V
Short-circuit current temperature coefficient: 2.0 MA/° C
Open-circuit voltage temperature coefficient: - 0.078 V/° C
Major system configuration:
1 Solar panels parameters: 15W (monocrystalline or polycrystalline)
2 System controller: 12V / 24 rotation 10A and intelligent control, LEDdisplay
3 Lead-acid battery: 12V12AH full sealed waterproof and moistureproof
Inverter, AC220V 150W
Output voltage: DC 12V AC 220V voltage ( special for 110V)
Cabinet: 508*332*73mm
Weight: 6.8 KG
The above information is only for reference. Our R&D team can design the systerm according to the local natural resources and customers specific requirements.
|
Name of designed electrical load |
model |
POWER |
Consumption Quantity |
Daily working time |
Daily consumption power |
|
Lighting product |
energy-saving light |
5W |
1 |
3 |
15Wh |
|
Applicace product |
fan |
25W |
1 |
2 |
50Wh |
|
Working product |
notebook |
45W |
1 |
2 |
90WH |
|
Total |
|
80W |
|
|
155Wh |
