8W IP68 Totally WaterProof Folding Solar Panel (PETC-SIP08)
This product is a multifunctional solar charger, with dual output(5V&12V) which can charge for 12V/9V battery and 5V iPhone/iPad, PDA, MP3, MP4, digital camera, video camera, PSP video games, iPhone, Blackberry, blue-tooth headset, iPod etc at one time. Foldable design, Graceful appearance, delicate and cabinet, Convenience to take, fashionable elegance. USB interface output can be suitable for most digital products, Especially suitable for anywhere can obtain sunshine, realize high-efficient charging, use convenient and safe, environmental protection, energy saving. It is good for promotion, sales, gifts etc.
1. Application:
Lights, 9V batterys, iPhones, iPads, smart phones, digital camera, MP3 etc.
2. Specifications
Solar Panel: 7W
Output: 12V&5V
High efficiency: > 17%
Double output: USB&DC5521
Extend Size: 580*185*13mm
Foldable Size: 195*185*15.8mm
Weight: 0.34KG
Color: Any color(Camoflague Green/pink ECT)
Color of cloth material, we can adjust to your specific requirement
3. Materials:
Solar panel: PET+EVA+Solar cell+PET+PCB+Waterproof 600D PVC
Fabric (waterproof): PVC
8W IP68 WaterProof Folding Solar Panel |
Product |
Folding Solar Panel |
Model |
PETC-SIP08 |
|
Peak-power (W) |
8W |
VPM (V) |
12V& 5V |
Maximum current (A) |
12V*0.66A& 5V*1.6A |
Voc (V) |
14.4V& 6.6V |
Isc (A) |
12V*0.73A& 5V*1.79A |
Maximum system voltage (V) |
1000V |
Cells conversion (%) |
18.5% |
Cells type |
Mono |
Cells String numbe (PCS) |
3pcs parallel |
Cells specification (mm) |
125x125 |
@ peak-power temperature coefficient Pm (%/ degree centigrade
) |
@ -0.45%/ degree centigrade
|
@ Voctemperature coefficient(%/ degree centigrade
) |
@ -0.35%/ degree centigrade
|
tolerance(%) |
± 5% |
@ Isc temperature coefficient(%/ degree centigrade
) |
@ +0.05%/ degree centigrade
|
Working temperature |
-30 degree centigrade
~70 degree centigrade |
Test standard |
@ Am1.5 25 degree centigrade
@ 1000W/ sq. m. |
NETWeight kg |
0.34 |
Waterproof IP |
IP68 |
Unfold Size |
580*185*13MM |
Foldable Size (mm) |
195*185*15.8MM |
The structure
Of Solar cells
|
PET+ EVA + PCB+waterproof fabrics |
accessories |
Controller /dual controller |
|
Price: |
Shenzhen Portable Electronic Technology Co., Ltd., is mainly devoted to the research, development, manufacture and sale of solar products and power supply. Our solar mobile/laptop chargers, portable power, solar modules, solar infrared security lights, solar street light, solar controller and solar home system etc supply have been successfully sold to clients in Europe, the USA, the Middle East, Asia, Australia and South Africa.
There is an elite R&D team in the company which is LED by the senior engineers in the solar energy photovoltaic application industry. With many years' technical accumulation and experience deposition, this team becomes full-fledged nowadays and involves into research and development based upon market application and information feedback from customers in the aspects of environmental-friendly energy, energy conservation, pollution and consumption reduction, intelligent illumination and control as well as electric hard disc.
Adhering to the principle of "Your success is our success", we pursue the goal of creating more values for our customers through providing higher application demands to different customers, promoting new products and forging rapid development paces diligently.
