| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,EXW |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T |
Technical parameter | |
AC600-1200kW | |
Rated voltage /Frequency | 3 Phase 4 Wire AC 600V/50Hz |
Max load power | Resistive load: 1000kW |
Load step | Resistive load: 14steps; 1, 2, 2, 5, 10, 10, 20, 50, 100, 200, 200, 200, 200, 200kW |
Power factor | 1 |
Load Tolerance(each step) | ±5% |
Load Tolerance(overall) | ±3% |
Display Precision | 0.5 class |
Control Power Supply | External AC380V/50Hz 3 phase 4 wire |
Wire Connection | Load Power Supply Input--Copper bar (star connection) Control power supply input--Connector bar |
Insulation grade | F class |
Duty cycle | Continuous |
Cooling | Forced air cooling, Horizontal inlet air, Upward cooling |
Transportation | Hoisting, there are lifting lug in top of casing and casters in bottom of load bank |
Casing Color | Grey(RAL7035) |
Dimension | About 2500 mm*2000mm*2000mm(length*width*height) |
Weight | About 1500kg |
Operating Environment Parameter | |
Ambient Temperature | -10ºC~+50ºC |
Relative Humidity | ≤95% |
Altitude | ≤2500 meters |
Atmospheric Pressure | 86~106kPa |
Main components brand | |
Contactor | Schneider |
Circuit Breaker | Siemens |
Fuse | Delixi |
SCM | Infineon |
Alloy Resistor | Kaixiang |
Data Management Software | Kaixiang |
| Prod Model: | AC600-1200KW |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Voltage: | AC600V |
| Frequency: | 50/60Hz |
| Max Load Power: | 1200kw |
| Power Factor: | 1 |
| Load Tolerance(Each Step): | ±5% |
| Load Tolerance(Overall): | ±3% |
| Display Precision: | 0.5 Class |
| Dimension: | 2500*2000*2000mm |
| Weight: | 1500kg |
| Insulation Grade: | F Class |
