Horizontal axis wind turbine 10kw, 3 pcs blades horizontal driectly drive, 3 phrase AC pma
on grid system kit
off grid system kit
Model Name: FD8-10kw
Rotor diameter: 8m/10m
Rated wind speed: 12m/s(FD10-10kw, rated wind speed is 9.8m/s)
Start up wind speed: 3m/s
Rated output power: 10kw
Max output power: 15kw
Working wind speed: 3m/s-30m/s
Survival wind speed: 50m/s
Generator type: PMG, 3 Phase AC generator
Working voltage: DC500V( can be choosed)
Tower type: Indepandance tower
Tower height: 10m(can be special ordered)
Gurantee: 2 years
Working life: 15-20 years
Application: Off-grid working system/on-grid working system
For ourput power curve, pls contract with us!
Qingdao Henryd Wind power Equipment Co., Ltd. is specialized small wind turbine generator manufacture in China. We own over 10 years practical experience in technical research, development and application of wind turbines. Also we have a strong r & d team to give our wind turbine tech supports. Our sales dept with many years experience in trading area will give you more supports.
We provide:
1)300w-30kw horizontal wind generator off-grid working system
1kw, 2kw,2.5kw 3kw, 5kw, 10kw, 20kw 25kw 30kw on-grid working system
2.)Vertical axis wind turbine 1kw 2kw,3kw 5kw
5-7 pcs stallout FRB blades.
3.) Variable pitch wind turbine 2kw 3kw 5kw 10kw 20kw 30kw 50kw 60kw
4.)2.2m-24m(diameter) frb, horizontal axis, 3 PCS aerofoil blades, past wind tunnel test, high efficiency.
5. )guy wire tower, independance tower, tilting up tower, hydraulic tower
--factory direct sales--
Good price and higher quality, provide technical support more professional.
