125kva/100kw Cummins Silent Diesel Genset
The advantages of the soundproof gen-sets
1. Nice shape and rational structure.
2. Perfect sealing: Rainproof, snow defence, dustproof and could work under the rugged environment.
3. Excellent security: The totally-enclosed box is made of 2 mm steel plates
4. Adequate ventilation: The temperature won't easily get high, which could guarantee the running power of gen-set.
5. Superb sound insulating: Protected gen-sets also have the function to lower the noise. Anti-drumming treatment could effectively lower the sectional noise during the running of the gen-sets.
6. Good operability: The designers adhere to the principle of individual-oriented ideas. In addition, they give full consideration to the convenience and safety of the operation.
More details of silent generator
Warranty:
The goods are under warranty against defects in material and workmanship for a period of 12 months or 1000 hours, whichever come first from the date of delivery to the end user except the damageable spare parts of genset caused by incorrect man-made operation, and that the aforementioned warranty for the same taken is back up by the engine and alternator suppliers.
125kva/100kw Silent Cummins diesel generators set |
Prime Power |
100Kw/125Kva |
Standby Power |
110Kw/137.5Kva |
Rated speed |
1500/1800rpm |
Frequency |
50/60HZ |
Voltage |
230/400V (adjustable) |
Phase and wire |
3 Phase and 4 Wires |
Dimension |
2210*830*1545 mm |
Weight |
1200kg |
Engine |
Brand |
Cummins 6BTA5.9-G2 |
Cooling |
Water cooling |
Governing system |
Electronic |
Bore(mm)*Stroke (mm) |
102*120 (mm) |
Alternator |
Brand |
Stamford UCI274E |
Characteristics |
Brushless, self-exciting |
Protection class |
IP23 |
Insulation |
H |
Power Factor |
0.8 |
