1. Super smalll weight
2. Super silence blades(10meter noise 58dba)
3. Super alternator output (same wind speed the output power more than other brands at least 15%. )
4. Super wind design(excelent design can be working in 3m/s to 49.2m/s wind speed)
Rotor Diameter: 47 inches (1.2m)
Weight: 12.3 lbs (5.6kg)
(Shipping: 26.5"X13.8"X8.3" (672X350X210mm) / 17.2 lbs (7.8kg))
Mount: 1.5" schedule 40 pipe (1.9" OD, 48 mm)
Magnetic Material: NdFeB (Neodymium Iron Boron)
Shaft Bearing: High Standard Sealed Bearing
Shaft: Stainless Steel
Fasteners (nuts and bolts): Stainless Steel
Start-up wind speed: 7 mph (3.13 m/s)
Voltage: 12 and 24 VDC
Rated Power: 400 watts at 28mph (12.5m/s)
Controller: Microprocessor-based smart external regulator with Peak Power Tracking
Blades: Carbon Fiber Composite
Body: Cast aluminum (Marine is powder coated for corrosion protection)
Energy Production: 38 kWh/mo @12mph (5.4m/s)
Warranty: 3 Year Limited Warranty
Survival Wind speed: 110 mph (49.2 m/s)
Over-speed Protection: Electronic torque control
Battery Bank Minimum: 100 AMP hours @ 12V, 50 AMP hours @ 24V
Smart external regulator with Peak Power Tracking Controller
1. Automatic Circuit Break protection.
2. High wind protection.
3. Constant output power display LED.
4. Over charge protection.
We engage in R&D, manufacture and sales of Wind generator, and emergency power system solution etc. Our products have been sold to Americas, Europe, Australia, Middle East, South and East Asia etc countrys. We have passed: CE, EMC certificate.
The company also has passed certificates of ISO 9001&ISO 14000 System.
In a word, welcome all over the world friend cooperate with us and make good friends. We can do it better!
