Outer Diameter:
14.0000 Inches
Inner Diameter:
14.6250 Inches
Breadth:
0.3125 Inch
Weight:
0.476kg
Rolling Body:
Ball Bearings
The Number Of Rows:
Single
Outer Dimension:
Large (',200-430mm)
Load Direction:
Radial Bearing
Material:
Bearing Steel
Separated:
Unseparated
Product Description
Luoyang Lirui Bearing Co. Ltd is a professional company engaged in the production of bearings, such as series of thin-wall deep groove ball bearing, angular contact bearing, four-point contact ball bearing.
There are three kinds of structure of thin-wall bearing, such as ARO, CPO, XPO, which are short for thin-wall angular contact series, thin-walled deep groove ball series and thin-wall four-point contact ball series.
We also specialize in the production of American KAYDON substitute precision thin section bearing, and Germany Substitute thin section bearing, imported substitute bearing, and Japan NTN substitute precision thin section bearing.
Thin section four-point contact ball bearing is an ideal choice for supporting moment heavy pressure. It successfully satisfies the four points contact between raceway and steel ball in order to support moment load and reversing axial load. Though it can be applied to withstand light load, it cannot completely substitute the radial contact ball bearing and angular contact ball bearing when supporting pure radial load.
Four-point contact ball bearing can bear radial load and two-way axial load. A single bearing can replace the positive combination or the back combination of angular contact ball bearings. They apply to pure axial load or synthetic load with larger axial load in it. Contact Angle (alpha) will be formed when the bearing withstand axial load from any direction, so the ring can always be in contact with the ball in any online points.
Main applicable cage: Copper alloy cutting cage Main use: Aircraft jet engines, gas turbine.
Type
Major dimensions
weight
Rated loading
Limiting speed
equivalent
d
D
B
radial
thrust
static
dynamic
static
dynamic
SILVERTHIN
IN
MM
IN
MM
IN
MM
KG
Co(N)
Cr(N)
Co(N)
Cr(N)
(RMP)
KB020XPO
2
50.8
2.625
66.675
0.3125
7.938
0.073
4850
3780
14010
10940
8650
SB020XPO
KB025XPO
2.5
63.5
3.125
79.375
0.3125
7.938
0.091
5960
4090
17170
11920
7110
SB025XPO
KB030XPO
3
76.2
3.625
92.075
0.3125
7.938
0.109
6890
4310
19880
12460
6040
SB030XPO
KB035XPO
3.5
88.9
4.125
104.775
0.3125
7.938
0.122
7960
4540
23040
13210
5250
SB035XPO
KB040XPO
4
101.6
4.625
117.475
0.3125
7.938
0.136
9070
4800
26200
13920
4640
SB040XPO
KB042XPO
4.25
107.95
4.875
123.825
0.3125
7.938
0.141
9560
4850
17580
14100
4380
SB042XPO
KB045XPO
4.5
114.3
5.125
130.175
0.3125
7.938
0.15
74730
4980
28910
14410
4160
SB045XPO
KB047XPO
4.75
120.65
5.375
136.525
0.3125
7.938
0.154
10630
5070
30740
14630
3950
SB047XPO
KB050XPO
5
127
5.625
142.875
0.3125
7.938
0.172
11120
5160
32070
14900
3760
SB050XPO
KB055XPO
5.5
139.7
6.125
155.575
0.3125
7.938
0.186
12190
5340
35230
15480
3440
SB055XPO
KB060XPO
6
152.4
6.625
168.275
0.3125
7.938
0.2
13300
5520
38390
16010
3170
SB060XPO
KB065XPO
6.5
165.1
7.125
180.975
0.3125
7.938
0.213
14230
5600
41100
16240
2940
SB065XPO
KB070XPO
7
177.8
7.625
193.675
0.3125
7.938
0.227
15350
5780
44300
16730
2740
SB070XPO
KB075XPO
7.5
190.5
8.125
206.375
0.3125
7.938
0.240
16460
5920
47460
17170
2560
SB075XPO
KB080XPO
8
203.2
8.625
219.075
0.3125
7.938
0.259
17530
6050
50620
17570
2410
SB080XPO
KB090XPO
9
228.6
9.625
244.475
0.3125
7.938
0.299
19570
6270
56490
18150
2150
SB090XPO
KB100XPO
10
254
10.625
269.875
0.3125
7.938
0.331
21750
6580
62810
19080
1940
SB100XPO
KB110XPO
11
279.4
11.625
295.275
0.3125
7.938
0.340
23800
6850
68680
19350
1770
SB110XPO
KB120XPO
12
304.8
12.625
320.675
0.3125
7.938
0.376
25980
7220
75000
20060
1620
SB120XPO
KB140XPO
14
355.6
14.625
371.475
0.3125
7.938
0.476
30070
7860
86740
21530
1400
SB140XPO
KB160XPO
16
406.4
16.625
422.275
0.3125
7.938
0.544
34300
8480
98970
22910
1230
SB160XPO
KB180XPO
18
457.2
18.625
473.25
0.3125
7.938
0.612
38520
9070
111160
24510
1090
SB180XPO
KB200XPO
20
508
20.625
523.875
0.3125
7.938
0.68
42750
9620
123350
26240
980
SB200XPO
