Product Description
Pelton Turbine
Pelton turbine suit to water head 100 to 1000 meters and with certain small flow. It could vertical and horizontal arrangement, nozzle numbers from one to six. Pelton turbine with feature of wide flow high efficiency region. It could start turbine with 10% of rated flow.
Pelton runner manufacture workmanship has been improved sharply in recent years. The runner could be wholly casted or forged and the shaped and polished by digital control machine tool. The factory tests including static and dynamic balance test, UT test, and dimension measurement.
Hydro turbine
Generator
Speed governor
Type of Valve
Type
Design Head (m)
Design Flow (m³ /s)
Power (kW)
Rated Speed (r/min)
Type
Rated Power (Kw)
Rated Voltage (v)
CJA475-W-90/2× 7
330
0.587
1702
750
SFW1600-8/1430
1600
6300
CWT/2
QF500-WY-40
CJA475-W-90/2× 7
444
0.678
2600
1000
SFW2500-6/1430
2500
6300
CWT/2
QF700-WY-40
CJA475-W-90/2× 9
273
0.883
2128
750
SFW2000-8/1730
2000
6300
CWT/2
QF400-WY-50
CJA475-W-110/2× 9
374
1.031
3404
750
SFW3200-8/1730
3200
6300
CWT/2
QF600-WY-50
CJA475-W-110/2× 9
431
1.118
4255
750
SFW4000-8/1730
4000
6300
CWT/2
QF600-WY-50
CJA475-W-110/2× 11
242
1.245
2660
600
SFW2500-10/1730
2500
6300
CWT/2
QF400-WY-60
CJA475-W-110/2× 11
285
1.353
3404
600
SFW3200-10/2150
3200
6300
CWT/2
QF400-WY-60
CJA475-W-115/2× 12.5
240
1.606
3404
500
SFW3200-12/2150
3200
6300
CWT/2
QF400-WY-65
CJA475-W-115/2× 12.5
278
1.733
4255
600
SFW4000-10/2150
4000
6300
CWT/2
QF400-WY-65
CJA475-W-115/2× 12.5
322
1.881
5319
600
SFW5000-10/2150
5000
6300
CWT/2
QF500-WY-65
CJA475-W-125/2× 9
581
1.293
6632
750
SFW6300-8/1730
6300
6300
CWT/2
QF800-WY-50
CJA475-W-125/2× 11
382
1.577
5319
600
SFW5000-10/2150
5000
6300
CWT/2
QF600-WY-60
CJA475-W-125/2× 11
447
1.690
6632
750
SFW6300-8/1730
6300
6300
CWT/2
QF700-WY-60
CJA475-W-125/2× 12.5
375
2.003
6632
600
SFW6300-10/2150
6300
6300
CWT/2
QF600-WY-65
CJA475-W-140/2× 11
520
1.855
8420
600
SFW8000-10/2150
8000
6300
CWT/2
QF800-WY-60
CJA475-W-140/2× 11
599
1.990
10526
750
SFW10000-8/2150
10000
6300
CWT/2
QF900-WY-60
CJA475-W-140/2× 12.5
440
2.167
8421
600
SFW8000-10/2150
8000
6300
CWT/2
QF600-WY-65
CJA475-W-140/2× 12.5
508
2.484
10526
600
SFW10-10/2600
10000
6300
CWT/2
QF700-WY-65
CJA475-W-140/2× 14
239
2.016
4255
428.6
SFW4000-14/2150
4000
6300
CWT/2
QF400-WY-70
CJA475-W-140/2× 14
277
2.175
5319
500
SFW4000-12/2151
5000
6300
CWT/2
QF400-WY-70
CJA475-W-140/2× 14
323
2.326
6632
500
SFW4000-12/2152
6300
6300
CWT/2
QF400-WY-70
CJA475-W-140/2× 14
378
2.523
8421
600
SFW4000-10/2153
8000
6300
CWT/2
QF400-WY-70
CJA475-W-160/2× 12.5
588
2.534
13158
600
SF12.5-10/2860
12500
10500
CWT/2
QF800-WY65
CJA475-W-160/2× 14
436
2.734
10526
500
SF10-12/2860
10000
6300
CWT/2
QF600-WY70
CJA475-W-160/2× 16
270
2.767
6632
428.6
SF6300-14/2860
6300
6300
CWT/2
QF400-WY80
CJA475-W-160/2× 16
316
3.018
8421
428.6
SF800-14/2860
8000
6300
CWT/2
QF500-WY80
CJA475-W-160/2× 16
365
3.249
10526
500
SF10-12/2860
10000
6300
CWT/2
QF500-WY80
Founded in 1978, Fuchun Industry Development Co., Ltd was moved to Shenzhen in 1998. In 2005, in the process of state-owned enterprise reform, our company has conglomeration and merger with GANZHOU COMPLETE SETS OF POWER GENERATING EQUIPMENTS MANUFACTURE Co., Ltd, dealing with all export projects, especially Complete Sets of Power Generating Equipments including design, manufacture, and installation and operation supervision, training.
Our factory has over 60 years experience in hydro power equipment manufacturing activities. We continue to hold the Fuchun's philosophy-adding product value, keeping good quality and providing good service.
Nowadays the company's business not only engages in manufacturing of small power equipment, but also covers engineering, design, procurement and construction of small and medium size hydro power plants (10kw-50MW) and coal-fired (biomass) power plants (200kw-25MW). We either wholly own or jointly own with other partners to have invested several factories in the power equipment industry, such as Jiangxi Ganzhou etc. We also dealing with small wind power generator and solar power plants, power substations, supply of power related equipment and machines of boiler, fan, pump, environment equipment (smoke flux treatment, water treatment), coal excavation facilities, dust and slag handling equipment, thermal power generation turbines, driving turbines, hydro turbines, wind turbines, generators, transformers, power cables, weight scales, cranes, bull dozers, analysis facilities and so on. Our company is also willing to take the contract of small and medium power generation factory consulting business because we have strong technical force of engineers and technicians.
In 30 years of the company history, we designed and manufactured a large mount of hydro turbine generators, not only for domestic China but also export to more than 30 counties, such as Guatemala, Ecuador, Congo, Pakistan, USA, Canada, Cuba, Germany, Austria, Turkey, North Korea, Viet Nam, Burma, Nepal, Norway, Denmark, Belgium, Uruguay, Russia, Georgia, Bulgaria, Bhutan, France, UK, Italy, etc.
Our company sincerely welcomes all clients, partners, and friends from all over the world to contact us for business co-operation. We believe that our efforts will bring you and us a win-win situation.
