| Price: | US $ 2450/Piece |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 1/Piece |
| Pay Type: | T/T |
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
|---|---|
| Output Type: | AC Three Phase |
| Cooling Method: | Water Cooling |
| Stroke: | Four Stroke |
| Installation Method: | Fixed |
| Type: | Basic Diesel Generator |
| Model |
50Hz, 400/230, COS=0.8, 3phase4wires |
Parameters of diesel engine 1500rpm |
Fuel consumption (full load) |
Dimension& weight | ||||
| Genset output |
Engine model |
Engine rated power |
Cylinders Type/No. |
mm | Kg | |||
| Prime | Standby | L× W× H | Weight | |||||
| KDE-Q10S | 8KW | 9KW | KM380D | 10KW | 3, in line | 2.5 | 1630× 790× 1150 | 350 |
| KDE-Q12S | 9KW | 10KW | KM385D | 11KW | 3, in line | 2.7 | 1630× 790× 1150 | 350 |
| KDE-Q13S | 10KW | 11KW | KM480D | 14KW | 4, in line | 3.1 | 1630× 800× 1150 | 370 |
| KDE-Q15S | 12KW | 14KW | KM485D | 17KW | 4, in line | 4.0 | 1630× 800× 1150 | 370 |
| KDE-Q23S | 15KW | 20KW | KM490D | 22KW | 4, in line | 5.0 | 1650× 800× 1150 | 450 |
| KDE-Q28S | 20KW | 22KW | KM498D | 25KW | 4, in line | 6.0 | 1700× 810× 1200 | 460 |
| KDE-Q30S | 24KW | 27KW | KM4102D | 33KW | 4, in line | 7.2 | 1700× 810× 1250 | 320 |
| KDE-Q38S | 30KW | 33KW | KM4105D | 38KW | 4, in line | 9.0 | 1700× 810× 1250 | 330 |
