| Prod Model: |
RDM-400F |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Number Of Blade: |
Three Blade |
| Stress Way Of Blade: |
Resistance |
| Rotating Shaft: |
Horizontal |
Product Description
Good economic returns, the modelling is exquisite, can be used as road landscape. Garden, highway or city street; Beach.
|
TECHNICAL PARAMETER |
400W |
|
Rated power |
400 W |
|
Maximum output power |
600 W |
|
Starting wind speed |
1.5 m/s |
|
Rated wind speed |
10 m/s |
|
Max wind speed |
60 m/s |
|
Blade quantity |
3 |
|
Rotating diameter |
1.6m |
|
Blade length |
1.8m |
|
Rated rotating speed |
260 rpm |
|
Generator weight |
18Kg |
|
Charging voltage |
24V |
|
2.BLADE |
|
|
Material |
Aluminum |
|
Blade quantity |
3 pcs |
|
Rotating diameter |
1.6 m |
|
Length |
1.8 m |
|
Start up wind speed |
1.5 m/s |
|
Rated wind speed |
10 m/s |
|
Rated rotating speed |
260 rpm |
|
3. GENERATOR |
|
Weight |
18 kg |
|
Size |
Φ350 * 80mm |
|
4. CONTROLLER |
|
Apparent power |
400W |
|
Rated input voltage |
24V DC |
|
Efficiency |
≥95% |
|
Breaker |
DC input >=23A |
|
Environment temperature |
-10 deg to +45deg |
|
Temp compensation |
YES |
|
Batteryreversal protection |
YES |
|
Load short circuit protection |
YES |
|
shell |
Aluminum |
|
Wind generator protection |
Manual/automatic |
|
Accident-oriented security |
YES |
|
Batteryoffline protection |
YES |
|
Cooling |
Force air cooling |
|
WARRANTY PERIOD |
|
Blade |
2 years |
|
Wind turbine |
3 years |
|
Controller |
1 years |
|
6. PRICE LIST |
|
|
No. |
Name |
Remarks |
|
1 |
400W wind generating set |
Generator, blade |
ZHEJIANG RDM TECHNOLOGY Co., Ltd. is a professional manufacture to do the solar panel, solar module. We can do all kinds of monocrystalline / polycrystalline(5W-300W) silicon solar modules according to our customer's different requirement. Our company has a productivity of 100MW units in 2010.
We have been trying to become the best PV products manufacturers in China.
We guarantee that our solar module have a plus tolerance 0-3%. We also provide OEM for other photovoltaic module.
The reason why RDM photovoltaic panel is authorized and chosen by the customers is its long-term high stability and low power attenuation. Its main features include:
1) It has passed the IEC 5400PA mechanical-load test and is able to withstand the worst, high load working environment;
2) 18 core quality monitoring points, 30 important quality monitoring points, and 100% of the current and voltage test ensure that it meets the power requirements of the power tolerance 0 ~ +3%;
3) It has passed a number of international certifications and tests (TUV, IEC61215&IEC61730, CE, CEC, RoHS, ISO)
