South America,Southeast Asia,Africa,Mid East,Eastern Asia,Western Europe
Prime Power Range:
8kVA~1500kVA
Alternator:
Leroy Somer or Stamford
Instrument For Adjusting Speed:
Electrical
Cylinder Amount:
4
Controller:
Smartgen/Deepsea
Protection Class:
IP22 / IP23
Rated Voltage:
127/220V; 110V/220V; 220V/380V; 240V/400V
Warranty:
1 Year or 1200 Hours
Type:
Self-Starting Diesel Generator
Installation Method:
Fixed
Stroke:
Four Stroke
Cooling Method:
Water Cooling
Output Type:
AC Three Phase
Speed:
1500rpm/1800rpm
Product Description
with UK Perkins engine Slinet Diesel Generator Set 8KVA~1500KVA 1, UK Origin Perkins Diesel Engine 2, Stamford/Leroy-somer/Marthon Alternators 3, 1-Year Warranty
General Data Sheet Engine and alternator mounted on the same frame steel skid. Built-in damper for anti-vibration.
Small size, low weight, easy to operate, installation and maintenance. World most famous brand diesel engine. UK origin Perkins series engine. World famous brand AC alternator: Stamford, Marathon, Leroy Somer, etc Advanced and reliable control module: Key start, Auto start, Remote control by PC with RS232/485 Full range protect function and alarm shutdown feature. ATS, Base Fuel Tank as Options
Genset Model
Prime / Standby Power
Engine Model
Alternator Model
No. of Cylinder
Fuel Consumption (L/H)
Genset Size (mm)
Weight (KG)
KVA
KW
Perkins
Stamford
L
W
H
GF3-07P
9/10
7.2/8
403D-11G
BY164B
3
2.4
1320
552
1258
400
GF3-10P
13.5/15
10.8/12
403D-15G
BY164C
3
3.48
1320
552
1258
450
GF3-16P
20/22
16/17.7
404D-22G
BY184E
4
5.4
1320
552
1258
470
GF3-24P
30/33
24/26.4
1103A-33G
BY184G
3
7.1
1470
620
1280
520
GF3-30P
37/41
30/33
1103A-33TG1
BY184H
3
10.7
1470
620
1280
580
GF3-36P
45/50
36/40
1103A-33TG1
BY184J
3
10.7
1470
620
1280
620
GF3-48P
60/65
48/52
1103A-33TG2
BY224E
3
14.1
1470
620
1280
650
GF3-52P
65/73
52/58
1104A-44TG1
BY224F
4
14.8
1590
710
1300
780
GF3-64P
80/88
64/70
1104A-44TG2
BY224G
4
18.7
1590
710
1300
850
GF3-72P
90/100
72/80
1104C-44TAG2
BY224G
4
21
1800
790
1350
980
GF3-80P
100/110
80/88
1104C-44TAG3
BY274C
4
24
1800
790
1350
1050
GF3-100P
125/40
100/112
1006TAG
BY274E
6
29
2300
820
1380
1200
GF3-120P
150/165
120/132
1006TAG2
BY274F
6
41
2450
880
1500
1350
GF3-144P
180/200
144/160
1106C-E66TAG4
BY274G
6
48.5
2600
910
1680
1550
GF3-160P
200/220
160/176
1306C-E87TAG3
BY274H
6
45.2
2980
980
1840
2050
GF3-180P
225/245
180/196
1306C-E87TAG4
BY274J
6
48.5
2980
980
1840
2150
GF3-200P
250/275
200/220
1306C-E87TAG6
BY444C
6
45
2980
980
1840
2550
GF3-280P
350/400
280/320
2206C-E13TAG2
BY444E
6
70.6
3100
1050
1980
2950
GF3-320P
400/450
320/360
2206C-E13TAG3
BY444F
6
81.1
3100
1050
1980
3000
GF3-360P
450/500
360/400
2506C-E15TAG1
BY544C
6
99
3300
1150
2195
3300
GF3-400P
500 / 550
400 / 440
2506C-E15TAG2
BY544D
6
106
3300
1150
2195
3950
GF3-480P
600 / 660
480 / 528
2806A-E18TAG1A
BY544E
6
95
3500
1150
2195
4550
GF3-520P
650 / 712
520 / 570
2806A-E18TAG2
BY544F
6
104.9
3500
1150
2195
4700
GF3-580P
725 / 800
580 / 638
4006-23TAG2A
BY634B
6
157
3900
1470
2195
5000
GF3-640P
800 / 900
640 / 720
4006-23TAG3A
BY634C
6
172
4400
1470
2195
5250
GF3-728P
910 / 1000
728 / 800
4008TAG1A
BY634D
8
206
4800
2050
2445
7400
GF3-800P
1000 / 1100
800 / 880
4008TAG2A
BY634E
8
214
4800
2050
2445
7650
GF3-1000P
1250 / 1375
1000 / 1100
4012-46TWG2A
BY634G
12
205
5000
2300
2875
8150
GF3-1090P
1363 / 1500
1090 / 1200
4012-46TWG3A
BY734B
12
205
5000
2300
2875
8950
GF3-1200P
1500 / 1650
1200 / 1320
4012-46TAG2A
BY734C
12
201
5000
2300
2875
9150
GF3-1360P
1700 / 1875
1360 / 1500
4012-46TAG3A
BY734D
12
212
5000
2300
2875
11200
GF3-1400P
1750 / 1925
1400 / 1540
4016TAG
BY734E
16
205
5400
2650
2650
13250
GF3-1460P
1825 / 2000
1460 / 1600
4016TAG1A
BY734E
16
206
5400
2650
2650
15500
GF3-1640P
2050 / 2250
1640 / 1800
4016TAG2A
BY734F
16
209
5400
2650
2650
18000
Fuan BoYuan Power Machinery Co., Ltd ( abbreviation: BY Power), Located in Fu'an City, Fujian Province, which is famous manufacturing industrial zone in Southeast China.
BY Power is specialized in manufacturing Diesel Generating Set, brushless alternator, AC synchronous alternator, and supplying various power products, like engine parts, controllers, ATS etc.
BY Power manufactures OEM generator powered by Cummins, Deutz, Volvo, MTU, Doosan engines and Stamford, Leroy Somer, Mecc Alte alternators. BY Power Generator set ranges from 7KW to 1200KW, 50Hz or 60Hz frequency, with open type, silent type, trailer type and containerized type, etc. All products are manufactured in accordance with the ISO9001 production standard to assure them of best quality produced and accepted for export to the international market. The products are mainly exported to Middle East, Africa & Southeast Asia countries and regions.
All staffs of produce and inspection team works for the industry more than 10years. They are professional and passionate for their job.
As a brand new profession manufacturer, our advantage is professional work team, strict inspection controll system and good service.
Our Advantages:
1. Solve your technical problems in 24 hours and provide international warranty service for engines
2. Design the appearance form according to customers' request
3. Polyester varnish for appearance protecting for shining and raining
4. Two hours testing before out factory
Warranty policy
The goods are under warranty against defects in material and workmanship for a period of 12 months or 1000 hours, whichever come first from the date of delivery to the end user except the damageable spare parts of genset caused by incorrect man-made operation, and that the aforementioned warranty for the same taken is back up by the engine and alternator suppliers.
