| Prod Model: |
SFDP2-033-035-41 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Motor Type: |
DC 12V/24V |
| AMPS: |
4.0max |
| Certification: |
CE,RoHS,ISO9001:2008 |
| Flow Rate: |
12.5lpm/3.3gpm |
| Pressure: |
35psi/2.4bar |
| Diaphragm: |
Santoprene |
| Valve: |
Viton or EPDM |
| Protection: |
Thermal/Ignition Protection |
| Duty Cycle: |
Intermittent |
| Port Dimension: |
1/2" NPT |
| Type: |
Pump |
| Drainage & Irrigation Mode: |
Sprinkler Irrigation Equipment |
| Application Field: |
Yacht/ RV |
Product Description
SEAFLO 24V farm water pump generator
12.5LPM/3.3GPM 35PSI
Backed SEAFLO's 1-Year Warranty!
Colors: Black or required
Application
1. Agriculture/Yacht / RV/Caravan pressurized water system
2. Sprayer fixture (Vehicle-mounted sprayer, electric sprayer)
3. Food beverage filling & liquid transfer
4. Any other pressurization system
How a Diaphragm Pump Works
The pump is driven by an AC or DC motor
In front of the motor is a valve assembly containing two to five valve pump chambers. Each valve chamber has a diaphragmbehind it in the lower pump housing. As the motor shaft turns, an internal cam positioned behind the diaphragms causes the diaphragms to be pushed forward, then back in a continuous sequence creating a suction. As this suction builds, fluid is pulled through the inlet, through the various valve chamber check valves to the outlet
The volume of flow is determined by several factors including: The number and size of the pump chambers, cam offset, operating pressure, fluid viscosity
|
Motor Voltage |
12/24V DC |
|
Type |
4 chamber diaphragm pump, self priming, capable of being run dry |
|
Mode |
Demand |
|
Certifications Option |
CE Approval |
|
Liquid Temperature |
140°F (60°C) Max. |
|
Priming Capabilities |
6 Feet (1.8 m) |
|
Max Pressure |
40psi (2.8bar) |
|
Max Flow rate |
17lpm (4.5gpm) |
|
Thermal Overload Protected |
Start working when temperature reach 90°C(+-10%) |
|
Inlet/Outlet Ports |
10/13mm pyramid hose barb, 13mm angle hose barb |
|
1/2 NPT thread filter for your choice. |
|
Duty Cycle |
Intermittent (under different pressure the continuous working time will also be different) |
|
Motor options |
2 pin connector |
|
On/off switch |
|
Model |
Switch |
GPM/LPM |
PSI/BAR |
Max Draw
(A) |
Valves |
Diaphragm |
Ports |
Voltage |
Wire
Connections |
|
SFDP1-027-017-41 |
Demand |
2.7/10.0 |
17/1.2 |
4.5 |
EPDM |
Santoprene |
Quick Attach |
12V |
2-Pin/Leads |
|
SFDP2-027-017-41 |
Demand |
2.7/10.0 |
17/1.2 |
2.0 |
EPDM |
Santoprene |
Quick Attach |
24V |
2-Pin/Leads |
|
SFDP1-033-035-41 |
Demand |
3.3/12.5 |
35/2.4 |
8.0 |
EPDM |
Santoprene |
Quick Attach |
12V |
2-Pin/Leads |
|
SFDP2-033-035-41 |
Demand |
3.3/12.5 |
35/2.4 |
4.0 |
EPDM |
Santoprene |
Quick Attach |
24V |
2-Pin/Leads |
