North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Warranty:
One Year, Spare Parts
Frequency:
50Hz/60Hz
Starter:
Electric Start/Recoil Start
Output Type:
AC Single Phase
Product Description
1. Accept small order
2. CE ISO EPA
3. Fast delivery time
4. Good afater sales...
Model
WY5500
WY6500
WY7500
WY8000
PICTURES
Bitmap
Bitmap
Bitmap
Bitmap
Engine Specs
Model
177F
188F
190F
192F
Horsepower@3600rpm
9hp
13hp
15hp
16hp
Displacement
270ml
389ml
420ml
435ml
Starting
Recoil
Recoil
Recoil
Recoil
Noise(7 meters amay ) (db)
69
72
74
74
Generator Specs
Rated Frequency(Hz)
60
60
60
60
Rated Voltage (v)
220
220
220
220
Rated Power output(KVA)
5
6
7
7.5
Max. Power Output(KVA)
5.5
6.5
7.5
8
Standard Feature
Large-capacity air-cleaner
Yes
Yes
Yes
Yes
Large-capacity fuel tank
Yes
Yes
Yes
Yes
Large-capacity muffler
Yes
Yes
Yes
Yes
Fuel indicator
Yes
Yes
Yes
Yes
Voltmeter
Yes
Yes
Yes
Yes
AVR
Yes
Yes
Yes
Yes
Oil alert system
Yes
Yes
Yes
Yes
Circuit breaker
Yes
Yes
Yes
Yes
Carton dimension(MM)
730x575x595
730x575x595
730x575x595
730x575x595
Model No.
WY3GF-3/3GF-4
WY3.5GF-3/3.5GF-4
WY4GF-3/4GF-4
WY5GF-3/5GF-4
WY6GF-3/6GF-4
Pictures
Bitmap
Bitmap
Bitmap
Bitmap
Bitmap
Generator
Noise(7meters away)
69db
70db
72db
74db
75db
Rated output frequency
50hz
50hz
50hz
50hz
50hz
Rated output voltage
220v
220v
220v
220v
220v
Rated ouput power
3.0kw
3.5kw
4.0kw
5.0kw
6.0kw
Max Output Power
3.3kw
3.8kw
4.5kw
5.5kw
6.5kw
Engine
Engine Model
173F/173FD
177F/177FD
182F/182FD
188F/188FD
190F/190FD
Engine type
4-stroke, 25 ″ inclinded single -clinder, air-cooled
BorexStroke (mm)
73x58
77x58
82x64
88x64
90x66
Displacement(ml)
242
270
337
389
420
Compression Ratio
8.2: 1
8.2: 1
8.0: 1
8.0: 1
8.2: 1
Theoretical Maximum
Output Power
5.8kw/3600rpm
6.6kw/3600rpm
8.0kw/3600rpm
9.5kw/3600rpm
10.5kw/3600rpm
Rated output power
5.1kw/3600rpm
5.4kw/3600rpm
7.1kw/3600rpm
7.8kw/3600rpm
8.5kw/3600rpm
Continuouse Operating
13hr
11.9hr
40hr
9hr
8.3hr
Horse Power
8Hp
9Hp
10Hp
13hp
15Hp
Max Torque
14.5N. m/3000rpm
15.5N. m/3000rpm
21N. m/3000rpm
23N. m/3000rpm
24N. m/3000rpm
Ignition system
Non-contact Transistorized Magneto(TCL)
Start System
Recoil Start /Electric Start
Air Cleaner
Semi-dry type /Oil bath type
Fuel Tank Capacity
25L
25L
25L
25L
25L
Fuel Consumption
1.9L/hr
2.1L/hr
2.45L/h
2.7L/hr
3.0L/h
Oil Capacity
1.1L
1.1L
1.1L
1.1L
1.1L
Packing Detail
Dimension (LXWXH)mm
735x555x580
735x555x580
735x565x590
735x565x590
735x565x590
Net Weight
65KG
67/69KG
77/79KG
80/82KG
83/85KG
Winyou - Chongqing Winyou Power Co., Ltd, located in Chongqing, China, is a leading manufacturer of power and garden equipment including gasoline and diesel engines, generators, water pumps, pressure washers, lawn mowers, tillers, etc with a variety of technical features.Winyou team have been working in this industry for over ten years with commitment to provide customers with quality, dependability and value.The pursuit of technological innovation and customer satisfaction is always the target of the team.Winyou power and garden products have the following features:
Meeting with local safety and environment standards;
Being designed to well-established and proven specifications;
Being reliable, durable and easy to start;
Having been tested and certified by well-known laboratories;
Coming with comprehensive manufacturer's warranties and services;
