Prod Model: |
HW-A-3k |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Model Number: |
Hw-a-3k |
Ozone Output: |
3000g/H |
Ozone Concentration: |
25mg/L |
Rated Power: |
51kw |
Power Supply: |
380V/3pH/50Hz |
Airflow Rate: |
56m3/H |
Cooling Water Flowrate: |
12m3/H |
Air Dew Point: |
-45oc |
Relative Humidity: |
<60% |
Type: |
Ozone Water Purifier |
Motive Force: |
Electric power |
Certification: |
CE |
Usage: |
Water Treatment |
Style: |
Micro-Gap Corona Discharge +Quartz Glass Tube |
Product Description
Ozonator for odor removal in livestock farm
We are OBM and ODM manufactory, We also accept OEM. We own our core technology, large sales teams, strong R&D team and standardized production workshop. Have strong competitive advantages on quality and price. Our R & D team always leads ozone technical reform and innovation. Our markets extend to all over the world. |
Item No. | Ozone Output (g/h) | Concen tration(mg/L) | Rated power(kw) | Air flow rate (m3/h) | Cooling water flow rate (m3/h) | Working pressure(Mpa) | Air dew point(°C) | Relative humidity | Power supply (V/Hz) | Power consumption (kwh/kgO3) | Weight (Kg) | Installation environment |
HW-A -3K | 3K | 35 | 51 | 56 | 12 | 0-0.2 | -45 | ≤60% | 380V/ 3PH /50H Z | 17 | 1400 | Indoor |
Description: |
1. Ozone generation concentration 0-60mg/L adjustable |
2. Microcomputer automatic control, human-machine interface display, a key type operation, easy and convenient |
3. Group control function, a host control platform machine, digital remote monitoring and control, real- time analysis and diagnosis system failure |
4. Ozone production adjustable |
5. Time switch machine Settings, realize unattended |
6. Three phase four wire power supply, don't disturb the power grid |
7. Ozone gas outlet own 0.2 Mpa pressure, it could transport gas without any external equipments during certain scope |
Application: |
1. Pharmaceutical factory clean area, cosmetic workshop clean area, disinfection sterilization, no secondary pollution, instead of traditional ultraviolet disinfection |
2. Food beverage factory processing water, animal husbandry and aquaculture water sterilization disinfection |
3. Swimming pool sea family house, disinfection sterilization except algae |
Remark: |
1. The final price will be subject to the approval sample and order quantity. |
2. Terms of payment: T/T 30% payment as deposit and the balance 70%T/T payment against the copy of B/L. |
3. Delivery time: 30 days after everything confirmed and receive 30% deposit. |
Our ozone high frequency inverters get many international patents. Less ozone generator suppliers could produce ozone generator at the same time produce soft-switch power supply system like us
Based on ozone technology, Fujian Allied Power EnTech Co., Ltd is a new high-technology enterprise which specializes in the line of ozone generation mechanism, ozone application, ozone material research and ozone equipment making. We cater to diversified industries and applications, which includes drinking water treatment, sewage treatment, swimming pools, public fields in hospital, pharmacy, paper making, printing and dyeing, etc. With an experienced Research & Development team, the company creates and produces the full series of ozone equipment based on the advanced technology and the right market location. We have the intellectual property of the whole series of ozone equipment core accessories. In a full range from the inverter to ozone discharge system, we apply a series of patented technology; We solve the matching problem between the power supply and discharge system to the full extent; We advance the efficiency and concentration of ozone generation. Then, the overall system of ozone generator has been recognized and appreciated by a lot of customers for its excellent reliability. Our company puts its business creed as "Allied technology, perfect quality. " We dedicates ourselves to the manufacture and technology innovation of ozone equipment and do our best for economic development and environmental protection.
