| Prod Model: |
YT-018 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model No: |
Yt-018 |
| Brand: |
Jiahuan |
| Ozone Output: |
100g |
| Voltage: |
220-110V/50-60Hz |
| Power: |
850W |
| Gas Source: |
Oxygen |
| Cooling Way: |
Water Cooling, Air Cooling |
| Capacity: |
95% |
| Material: |
Stainless Steel |
| Warranty: |
12 Months |
| Structure: |
Portable |
| Usage: |
Industry |
| Air Volume: |
>400m³/h |
| Type: |
Ozone |
| Certification: |
RoHS |
| Application Area: |
>61m² |
| Power Source: |
Electrical |
| Operating Principle: |
Active |
| Purifying Technology: |
Ozone |
Product Description
Product descriptions:
technology date:
| Model No | Ozone output(g/hr) | Power(W) | Voltage(V) | Size(cm) | Weight(kg) | Oxygen generator |
| YT-015 | 5g/h | 660W | 220-110V/50-60HZ | 55*44*73cm | 40kg | In-built |
| YT-015 | 10g/h | 680W | 220-110V/50-60HZ | 55*44*73cm | 43kg |
| YT-016 | 15g/h | 780W | 220-110V/50-60HZ | 55*44*88cm | 50.8kg |
| YT-016 | 20g/h | 850W | 220-110V/50-60HZ | 55*44*88cm | 50.8kg |
| YT-016 | 30g/h | 950W | 220-110V/50-60HZ | 55*44*88cm | 50.8kg |
| YT-016 | 40g/h | 110W | 220-110V/50-60HZ | 55*44*103cm | 52kg |
| YT-017 | 50g/h | 1200W | 220-110V/50-60HZ | 55*44*103cm | 52kg |
| YT-017 | 60g/h | 1300W | 220-110V/50-60HZ | 55*44*103cm | 75.5kg |
| YT-017 | 80g/h | 1750W | 220-110V/50-60HZ | 55*44*138cm | 86.5kg |
| YT-018 | 100g/h | 2650W | 220-110V/50-60HZ | 55*44*143cm | 106.5kg |
Features:
1. Carbon steel sprayed with plastic housing;
2. Built-in PSA high purity twelve tower oxygen sieve;
3. Built-in patent of product -Air cooling Ceramic ozone tube with high frequency electric board, high
ozone concentration and stable ozone capacity, long life time;
4. Built-in Oil-free air compressor;
5. Built-in Air dryer and filters. To supply cool, dry, clean air source for air compressor and PSA
oxygen concentrator;
6. Manual control, easy operation and maintenance.
Control panel:
Voltmeter, Amp meter, Timer, Ozone Amp meter, Main switch, Power supply switch, Emergency stop,
working light, Power light, Alarm
Control protection:
Over current protection
Electric leakage protection
Short circuit protection
Over heat of air compressor protection
Time delay system protection
Applications:
1. Aquactulture,Aquarium,Fish farming Water treatment
2. Cooling towers water treatment
3. Swimming pools Water treatment
4. Sewage water treatment
5. Water Disinfection& sterilization
Packaging & Delivery
Packaging Detail: | 1pcs/wooden case |
| Delivery Detail: | can be arranged promptly |
Guangzhou Jiahuan Application Techology Co. Ltd has lined in ozone generator for over 10 years, with high quality and reasonable price for our dear customers. And we have a very good reputation on the markets. We are manufacture of the ozone generator varied from 5g/hr to 2kg/hr ozone with oxygen feeding or air feeding, 3LPM to 300LPM PSA oxygen generator/concertration, car air purifier with ozonizer and ionizer, ozonated water machine, erc.
