Cummins series Deutz series lovol series MAN serie
Product Description
Handa produces (20kw-1200kw)/gen_set(20kw-1200kw)
(20kva-1200kw)silent generating sets(20kva_1200kw)
Mobile type generator set
(20kw-1200kw)/automatic series generating sets(20kw-1200kw). As per the requirments of customers, we can offer all kinds of diesel engine(wheichai series, deutz series, lovol series, volvo series, cummins series, man series)and alternators(marathon, stamford, qianghui, leorysome
Genset Model
Unit
HDC20GF
HDC30GF
HDC40GF
HDC64GF
HDC80GF
Rated Output
KW
20
30
40
64
80
KVA
25
37
50
80
100
Backup Output
KW
22
33
45
70
88
KVA
27
40
56
88
110
Rated Current
A
36.1
54
72
116
144
Rated Voltage
V
230/400
230/400
230/400
230/400
230/400
Fuel Consumption
≤ g/kw. h
214
214
216
214
214
Rated Frequency
HZ
50
50
50
50
50
Power Factor
0.8
0.8
0.8
0.8
0.8
Connection Type
3-pharse 4-Wire
Overall Dimensions
(L*W*H)
1565× 720× 1100
1630× 720× 1100
1680× 720× 1160
2120× 830× 1375
2240× 830× 1375
Gross Weight
KG
780
840
880
1060
1190
Engine Model
4B3.9-G
4BT3.9-G
4BTA3.9-G
6BT5.9-G
6BT5.9-G
Trademark & O/L
CUUMINS
CUUMINS
CUUMINS
CUUMINS
CUUMINS
Type
Water-cooled, in line four-stroke, Humit cylinder, Liner direct injecion
Cylinder Number
4
4
4
6
6
Bore& Stroke
mm
102× 120
102× 120
102× 120
102× 120
102× 120
Displacement
L
3.9
3.9
3.9
5.9
5.9
Rated Output
KW
24
36
50
90
90
Speed
r/min
1500
1500
1500
1500
1500
Starter
24v
Hebei HANDA Engineering Machinery Co., Ltd., was founded in 2006 with its headquarters YueShou Group located at the foot of Mount Tai, which covers an area of 110, 000 square meters and possesses more than 1200 staff, including 164 engineering technicians (within 14 masters and 4 doctors), and 87 skilled workers.
In the past years, our average yearly turnover reached 1 Billion RMB with almost 30% export. The market shares of Asphalt Mixing Plant, Concrete Mixing Plant and the Generator set are first place among domestic production.
HANDA mainly focus on the design, manufacture, and installation of generator, road building and construction machinery. HANDA Engineering Machinery Co., Ltd has been certified for State GB/T19001-2000(ISO9001: 2000) Quality Standard System Authentication Certificate and GB/T19022.1 Measurement Qualification Confirmation.
We have established long-term partnerships with bureaus of the China Railway Construction, the China Railway Engineering, the China Transportation Construction Group, and more. Especially, we have supplied more than 100 sets of Concrete Mixing Plant for the 9 Passenger Railway lines projects being constructing, and made a great contribution to the high-speed railway engineering of China in the first year of the Eleventh-Five-Year Plan.
In resent years, we have been exploring the international markets, and our products have been exported to Russia, Indonesia, Nigeria, Philippines, Malaysia, Mongolia, and so on. The demand is increasing year by year simultaneously. What's more, HANDA has extensive technical exchange and cooperation with many famous engineering machinery enterprises in Germany, Italy, South Korea, Japan and Spain, which ensures our products' quality and technology keep pace with the world development.
Featuring the self-supporting mechanism, perfect network, and unique concept, HANDA Engineering Machinery carries out star-level service and full process of pre-sales, on-sales, and after-sales support.
