North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Colour:
Per Customer's Request
Power:
169/184kw
Certification:
ISO9001
Cooled Type:
Water
Body Material:
Aluminium
Structure:
Sealed Type
Brand:
Huizhi
Use:
Generator
Product Description
Specification:
1. Product name: Generator engine radiator for Shangchai Power
2. Model: SC4H250D2
3. Colour: Per customer's request
4. Power: 169/184KW
5. Certification: ISO9001
6. Cooled type: Water
7. Body material: Aluminium
8. Structure: Sealed type
9. Brand: Huizhi
10. Use: Generator sets
First cooperation common flow:
1.？Request customer to send us？the？drawings,？or？offer？the？photos,？main？parameters,？dimensions？and other necessary？data,？etc.
？
2.？Our？tech.？dept.？issued？the？drawings？according？to？the？information？offered？by？customers in 24 hours.？And？send？it？for？customer's？confirmation.
？
3.？We send the？quotation？to？customers in 24 hours after？receipt？of？the？confirmation？of？drawing.
？
4.？ After？both？parts get the？agreement？about？price,？kelong？will arrange？sample？producing,？then？send？it？for evaluation？by？customers.
？
5.？The customers？are requested to？offer？the？test？result.？And？Kelong？will？update？the？design？according？to？the？test？result if need it.
？
6.？After conclude？the？final？confirmation？of？the？product both of us.？？We？will？start？the？mass？producing？cooperation.
Company brief construction:
？Henan Pingyuan Radiator Co.,Ltd,founded in 1987,is a professional manufacturer of radiator,which has the comprehensive capacity of the development, design, manufacture and sale of the radiator on internal combustion engine and the cooling system on automotive engine. She has passed ISO9001:2000 quality system certification and ISO/TS16949:2002 quality management system certification. Moreever,"Provincial Enterprise Technology Center"and？"Municipal Aluminium Radiator Engineering Techonology Research Center"have been set up in it.Up to now,she has received 10 patents,and her aluminium radiator series for motor lorry wins the prize of？"Provincial Scientific and Technical Achievements".The company is successively awarded the honorable titles:"the contract trustworthy enterprise of Henan Province","the AAA level credit enterprise of Henan Province","the fast-developing private enterprise of Henan province"？and？"the characteristic industry an dadvanced enterprise of Xinxiang city".
？ There are more than 500 sets of equipments,such as electrostatic spray automatic production line,36 CNC punch press,vacuum brazing furnace,core-assembling machine,and so on.In addition,she has developed and built up lots of innovative production lines for aluminium radiator,copper radiator,automotive radiator,radiator of agricultural machinery,air cooler,plate-fin oil cooler,and so on.Moreover,there are more than 50 sets of specialized test equipments in the company,such as sealed-pressure-test machine,anti-vibrating-testing equipment,impulse-testting machine,specialized equipment for testing acid and alkali resistance,and so on,which ensure that the products have the excellent performance. The main products are as follows:135 series, Cummins Series, Mercedes-Benz Series,190 Series, MTU series, Daewoo series, DEUTZ series ,Steyr series, Volvo series, Caterpillar series, radiator of engineering machinery, heat exchanger, seawater-to-freshwater exchanger, and so on. They are well received not only in china but also in Singapore, Turkey, India, Southeast Asia and Europe,and keep ranking the first in the radiator industry of Henan province for three years.
？ In short, with advanced technology, sophisticated manufacturing equipments and complete testing methods, we are dedicated to providing the most perfect products with the high quality and most preferential price and the most generous service to society, make our human-oriented management concept benefit more.
Key production equipment:
Advanced test machine:
Production process flow map:
？
Product key parameters
MODEL
SC4H250D2
POWER
169/184KW
OVERALL DIMENSION
870×550×1204
INSTALLATION
840×100×50
CENTER HEIGHT
565
MATERIAL
Aluminium (we can also make Aluminum radiator )
AMBINENT TEMPERATURE
40°C ( we can also make 50°C radiator if the customer ask )
CERTIFICATION
GB/T19001-2008__ISO 9001:2008
We can also manufacture the clients' pattern as they offer. We also design the radiator according to customer's request .
our products are both best quality and reasonable in price , welcome to choose our company's product.
MODEL
OVERALL DIMENSION
INSTALLATION DIMENSION
CENTER HEIGHT
POWR
4135D
897*750*370
704*182
440
58KW
4135AD
897*750*370
704*182
440
75KW
4135AZD
897*750*370
704*182
440
88KW
6135D
931*864*362
824*182
468
90KW
6135AD
931*864*362
824*182
468
120KW
6135AZD
931*864*362
824*182
468
155KW
G128ZD
1230*1165*395
970*100
600
236KW
G128ZLD
1230*1165*395
970*100
600
309KW
12V135AZD
1515*1332*367
1182*100
770
330KW
12V135AZLD
14655*1345*620
1270*260
740
514KW
12V135BZLD
1760*1650*605
1350*260
875
555KW
All the products among research and development must pass the below tests:
1.Performance Test
a.Single radiator wind tunnel test
b.Combination of cooling system wind tunnel test
2.Reliability Test
a.Vibration test
b.High temperature&pressure pulse test
c.High&low temperature test
d.Thermal shock test
e.Leakage test
f.Inside&outside corrosion test
3. Raw Material Test
a.Performance test:Anti-tensile Strength,Hardness,Eriehsen test
b.Metal element spectrum analysis
Henan Pingyuan Radiator Co., Ltd, founded in 1987, is a professional manufacturer of radiator, which has the comprehensive capacity of the development, design, manufacture and sale of the radiator on internal combustion engine and the cooling system on automotive engine. She has passed ISO9001: 2000 quality system certification and ISO/TS16949: 2002 quality management system certification. Moreever, "Provincial Enterprise Technology Center"and "Municipal Aluminium Radiator Engineering Techonology Research Center"have been set up in it. Up to now, she has received 10 patents, and her aluminium radiator series for motor lorry wins the prize of "Provincial Scientific and Technical Achievements". The company is successively awarded the honorable titles: "the contract trustworthy enterprise of Henan Province", "the AAA level credit enterprise of Henan Province", "the fast-developing private enterprise of Henan province" and "the characteristic industry an dadvanced enterprise of Xinxiang city".
The company is situated in Weihui, an ancient city in north Henan, which is 80 kilometers from the provincial capital. Jing-zhu Highway, No. 107 National Road and Xin-PU Provincial Road lay across the city. The transportation is very convenient. The company covers an area of 95, 000 square meters, and the employs more 500 people with 126 professional technicians. There are more than 500 sets of equipments, such as electrostatic spray automatic production line, 36 CNC punch press, vacuum brazing furnace, core-assembling machine, and so on. In addition, she has developed and built up lots of innovative production lines for aluminium radiator, copper radiator, automotive radiator, radiator of agricultural machinery, air cooler, plate-fin oil cooler, and so on. Moreover, there are more than 50 sets of specialized test equipments in the company, such as sealed-pressure-test machine, anti-vibrating-testing equipment, impulse-testting machine, specialized equipment for testing acid and alkali resistance, and so on, which ensure that the products have the excellent performance. The main products are as follows: 135 series, Cummins Series, Mercedes-Benz Series, 190 Series, Perkins Series, MTU series, Daewoo series, DEUTZ series, Steyr series, Volvo series, Caterpillar series, radiator of engineering machinery, heat exchanger, seawater-to-freshwater exchanger, and so on. They are well received not only in China but also in Singapore, Turkey, India, Southeast Asia and Europe, and keep ranking the first in the radiator industry of Henan province for three years.
In short, with advanced technology, sophisticated manufacturing equipments and complete testing methods, we are dedicated to providing the most perfect products with the high quality and most preferential price and the most generous service to society, make our human-oriented management concept benefit more.
