Air-cooled 4-stroke, OHV, 25°inclined single cylinder
Bore×stroke mm
70×54
Displacement ml
210
Compression ratio
8.5:1
Max power kW/rpm
3.9/3600
Rated power kW/rpm
3.7/3600
Max torque N.m/rpm
11.5/3000
Ignition system
Transistorized magneto
Starting system
Electric
Air cleaner
Foam element
Oil capacity L
0.6
Lowest fuel consumption g/(kw.h)
≤395
GENERATOR
Max power
2.2kw
Rated power
2kw gasoline generator
Rated voltage V
12(DC)
110/120(AC)
Rated circuit A
8.3(DC)
17(AC)
Voltage regulation
AVR
Rated frequency Hz
50/60
Phase
Single
Power factor COSφ
1
Material of winding
Copper
Insulation level grade
F
Sound pressure level (rated power at 7meter)
69
Fuel tank capacity L
15
Continuous work time at rated power/full tank hrs
9
Dimension L×W×H mm
605×440×455
N.W/G.W kg
42/44
Fuel
gasoline generator
20FT, 40FT set
240, 495
Features
Benefits
1).Compact design
Easier to store or take with you
2).Low weight
Easy to carry from job to job
3).Excellent portability
Sturdy base with rubber footers for secure placement
4).Convenient grab handle
Makes lifting easy, even when generator is hot
5).Larger fuel tank.
Extended operation time for more hours between refuels
6).Contact-less TCI ignition
For a stone reliable spark
7).Easy operation switches
Easy to find and use in low light
8).Brushless generator unit
No maintenance required,1 Year of worry-free service
9).Light-pull recoil start
Makes starting a breeze for younger or weaker operators
10).Circuit breaker system and Low oil pressure protection
Reliable protection
we also have:
Model
Rated Power KW
N.W.(kg)
G.W. (kg)
Dim(mm)
20GP/Qty(sets)
40GP/Qty(sets)
SD2500
2.0
38
40
605x455x440
240
580
SD3500
2.5
40
42
605*455*440
240
580
SD6500
5.0
80
82
690X520X550
140
285
SD8500
6.0
82
84
690X520X550
140
285
we also have : diesel generator generator set: 3kw-1000kw gas generator set: 10kw-500kw
Dongying Shengdong Dynamoelectric Facility Co., Ltd. Located in the birthplace of China's second largest oilfield Shengli Oilfield, the beautiful and rich Yellow River Delta, is a professional engaged in generating R & D, manufacturing, sales and service of high-tech companies. The company occupies 12, 658 square meters, 12 senior engineers, 120 professional and technical personnel, with more than 300 employees.
The company is specialized, with strong technical force, complete production equipments, advanced production technology, complete detection means, test the system in strict accordance with ISO9000 -2.0 thousand of quality management system requirements.
The company mainly produce generator, gasoline generator, diesel generator sets, gas generator sets and other four series of mechanical and electrical products. For the purpose of making the customer satisfied, the company continuous improve product performance, and always insist that quality comes first, faith-based management approach, in order to win the majority of customers trust and praise.
The company can meet customers different voltage requirements of different frequencies to achieve multiple units in parallel with the model grid, as well as automation of common type change-type generating units.
In order to ensure customer satisfaction, the company can offer a full-time maintenance staff 24 hours a day around the clock at any time for the majority of users, and provide installation, commissioning, maintenance, repair one-stop service.
Dongying Shengdong Dynamoelectric Facility Co., Ltd. Is sincerely willing to cooperate with you and seek common development.
