| Prod Model: |
EM400 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| High Efficiency: |
Quality |
| Number Of Blade: |
Three Blade |
| Stress Way Of Blade: |
Resistance |
| Rotating Shaft: |
Horizontal |
Product Description
The EM 400 is popular sight in home yard, streetlights, boats, advertizing signs and telecommunications tower etc. Thousands have been sold and are in use worldwide. People have the particular inclination for it's clean, aerodynamic lines and its quiet and continuous operation. Without any doubt EM 400 accumulates more energy than any other comparable wind generator available, you'll always see a Calla Glory spinning in the lightest of breezes!
|
Model |
EM400W |
|
Rated Power (W) |
400W |
|
Max Power (W) |
400W |
|
Rated Voltage (DCV) |
12/24V |
|
Rated Current (A) |
25/12.5 |
|
Efficiency |
0.85 |
|
Output Voltage of Inverter |
As concrete requirements by clients |
|
Rotor Diameter (m) |
1.5 |
|
Start-up Wind Speed (m/s) |
1.5 |
|
Direction (Looking Downwind) |
Clockwise |
|
Location Relative to Tower |
Upwind |
|
Rated Wind Speed (m/s) |
30 |
|
Security Wind Speed (m/s) |
35 |
|
Protection Mode |
Yaw and Dumpload |
|
Rated Rotation Speed (r/m) |
450 |
|
Shell Material |
Aluminum Alloy |
|
Blade Material |
Nylon |
|
Blade Quantity |
6 |
|
Guy-Cable Tower |
Height (m) |
6 |
|
Free-Standing Tower |
Height (m) |
/ |
|
Hydraulic Tower |
Height (m) |
/ |
|
Suggested Battery Capacity |
12V150Ah 2pcs |
|
Control System |
Controller and Modified Wave Inverter |
|
Standard Supply Scope |
Wind turbine generator system including turbine, hub, controller, off grid inverter, blades, tower and other accessories |
|
Turbine Life Span |
Around 20 years under normal wind conditions |
Calla Glory Wind Power is a wind turbine manufacturer with headquarters and main production facilities established in 1998.Calla Glory Wind Power is wholly owned by Calla Glory through the Renewable Energy division in the Calla Glory Enterprise Corporation Limited.The renewable energy constituent company is one of leading and the largest producers and exporters for Small-medium sized Wind Turbines from 300W up to 50kW.Calla Glory Wind Power is specialized high-tech enterprise engaged in independent development, design, manufacturing and sale of small wind generators which are adaptable to a global variety of wind resources and environmental conditions.
Whole-digitalized controlling system has been achieved through the appliance of ultrasonic anemoscope and dogvane in 10KW wind turbine generator, 20KW wind turbine generator, 30KW wind turbine generator and 50kW wind turbine generator developed by our company.The wind generator has been adopted low-torque starting technique with start-up wind speed 2m/s.The appliance of several new technologies contributes to the simplification of installation procedures, reduction of taking room, advancement of electric efficiency, along with enhancement of stability and security, received warm welcome from customers both domestic and aboard.
