Type:
Open Type
Starting Modle:
Electric Start or Handle Start
Output Type:
AC Three Phase
Product Description
1. CE approved diesel generator, powered by advanced air-cooled diesel engine.
2. New automatic voltage regulator(AVR) ensures steady voltage output.
3. Low oil pressure alarm system, which can shut down the engine automatically.
4. Electric start system ensures rapid start of the diesel generator set.
5. 3-phase output meets the diversified demands from customer.
Model
KDE2500E
Frequency (HZ)
50
60
Rated Output (KVA)
1.7
2.0
Maximum Output (KVA)
2.0
2.2
Rated Voltage (V)
115/230
120/240
Rated current (A)
14.8/7.4
16.7/8.3
Rated rotation speed (rpm)
3000
3600
Phase No.
Single phase
Power Factor
1.0
Excitation Mode
Self-excitation, 2 pole and constant voltage (AVR)
DC Output
12V. /8.3A , Terminal Post
Noise Level (7m) dB(A)
77
Engine Model
KM170FE
Engine type
Single-Cylinder, Vertical, Four-Stroke, Direct Injection, Air Cooled Diesel
Bore × Stroke(mm)
70 x 55
Displacement (L)
0.211
Rated Power KW
2.5/3000
2.8/3600
Fuel comsumption Rate(g. kw/h)
280.2
288.3
Compression Ratio
20: 1
Lubrication System
Pressure Splashed
Starting System
Electric Start with 30Ah MF battery
Fuel Type
0#(summer)-10#(winter) diesel
Lube Oil Brand
SAE10W30 (above CD Grade)
Lube Capacity (L)
0.75
Fuel Tank Capacity (L)
12.5
Continuous Running Time (hr)
20
Overall Dimension: LxWxH (mm)
660 x 500 x 570
Dry Weight (Kg)
60
Quantity in 20FT
132 Pcs
Optiomal Features: Remote, ATS(Auto Transfer Switch), Digital Panel
We reserve the right to change specifications without notice
