| Prod Model: |
QSV-456GF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Frequency: |
50Hz |
| Color: |
Deep Green |
| Power: |
456kw/570kVA |
| Cylinder No.: |
6 |
| Bore/Stroke: |
144*165mm |
| Size(L*W*H Mm): |
3300*1200*1850 |
| Weight(Kg): |
3500 |
| Rated Rpm: |
1500/1800/3600 |
| Displacement: |
16.12L |
| Lubricating Capacity: |
48L |
| Type: |
Basic Diesel Generator |
| Installation Method: |
Portable |
| Stroke: |
Four Stroke |
| Cooling Method: |
Water Cooling |
| Output Type: |
AC Three Phase |
Product Description
Volvo diesel generator
1. Volvo brand diesel engine
2. OEM service from Volvo
3. Easy to operate
4. Low oil consumption
| Diesel Generator Specifications |
| Manufacturer: | Yangzhou yangke machinery electric Co.,Ltd. |
| Model: | qsv-456 |
| Prime Power: | 456KW / 570KVA |
| Standby Power: | 510KW / 640KVA |
| Frequency: | 60HZ |
| Voltage: | 440/254V |
| Phase: | 3 Phase |
| P.F: | 0.8 |
| Fuel: | Diesel |
| Rated Current: | 820A |
| Start Method: | 24V DC Start Battery |
| Accessory: | Battery, wire, exhaust pipe, muffler, damper, breaker |
| Altitude: | ≤1000m |
| Engine Specifications |
| Manufacturer: | Sweden Volvo |
| Model: | TAD1642GE, 4-cycle |
| Air Intake System: | Turbo, Air/Air Cooling |
| Fuel System: | Elec. Injection, Elec. Fuel system |
| Cylinder Arrangement: | 6 in line |
| Displacement: | 16.12L |
| Bore and Stroke: | 144×165 mm |
| Compression Ratio: | 16.5 |
| Rated RPM: | 1800rpm |
| Maximum Output Power: | 546KW/743HP(with fan) |
| Governor Type: | EMS2 |
| Exhaust System |
| Exhaust Gas Flow: | 110.4m3/min |
| Exhaust Temperature: | 479ºC |
| Max Back Pressure: | 10kPa |
| Air Intake System |
| Max Intake Restriction: | 5kPa |
| Burning Capacity: | 45.8m3/min |
| Air Flow: | 744m3 /min |
| Fuel System |
| 100%( Prime Power) Load: | 206 g/Kw.h |
| 75%(Prime Power) Load: | 202 g/Kw.h |
| 50%(Prime Power) Load: | 204 g/Kw.h |
| 100%( Prime Power) Load: | 117.9L/h |
| Oil System |
| Total Oil Capacity: | 48L |
| Oil Consumption: | 0.11L/H |
| Engine Oil Tank Capacity: | 42L |
| Oil Pressure at Rated RPM: | 300-650kPa |
| Cooling System |
| Total Coolant Capacity: | 60L |
| Thermostat: | 86-96ºC |
| Max Water Temperature: | 103ºC |
| Alternator Specifications |
| Rated Capacity: | 456kw |
| Winding: | 100% Copper Wire |
| Frequency: | 60HZ |
| Speed: | 1800 RPM |
| Connecting Type: | 3 Phase and 4 Wires, "Y" type connecting |
| Power Factor: | 0.8 |
| Protection Grade: | IP23 |
| Exciter Type: | Brushless, self-exciting, with AVR |
| Insulation Class, Temperature Rise: | H/H |
| Voltage Regulation: | ≥±5% |
| Control System Specifications |
| Manufacturer: | DEEP SEA ELECTRONICS PLC (UK) |
| Model: | DSE6020 |
| Type: | AMF Automatic Operation |
| Operation: | Automatic Start and Auto Mains (Utility) Failure Control |
| Alarm Protect: | Engine pre-heat, Current monitoring, Comprehensive Shutdown, Charge Failure |
Packaging & Delivery
| Packaging Detail: | generator standard exporting package |
| Delivery Detail: | within 5-25working days after the deposit |
Company Information
Yangke Machinery Electric is a high-tech generator manufacturer which contains R&D, production and marketing together.
Our company not only establishes humanized modern enterprise with perfect quality management system and certification authority, but also equipped with international advanced facilities of R&D, manufacture and test. The concept of our company is to develop the best product, to provide the best service. We will spare no effect to serve our customer with products of high quality and after-sales service in a variety of ways.
With the help of the technical strength, our company has formed a structure of product series. The current main products are: QS series 8-3000KVA brushless alternators, which can be coupled with both domestic and foreign brands of diesel engines.
We only offer products using major engine brands such as Cummins, Perkins, Doosan, MTU Diesel/Mitsubishi etc. At YANGKE, we also customize the standard models to meet your unique requirements. Our Generators are also top of the line and come with base mounted fuel tanks, battery, battery rack and cables, vibration isolators between engine/diesel generator and base frame, a circuit breaker to protect the generator from overload and a two-wire auto start ready controls for automatic transfer switch operation. (Note: Automatic Transfer Switch Required for True Auto Operation).
Our products are sold to Southeast Asia, central Asia, the Middle East, Africa and South America.
Sales promises:
YANGKE power provides a full line of brand new and high quality products. Each and every unit is strictly factory tested.
Warranty is according to our standard conditions :
a. 15months,counted on the day YANGKE sold to the first buyer;
b. one year after installation;
c.1000running hours(accumulated),subject to the earlier one.
Service and parts are available from YANGKE POWER or distributors in your location.
FAQ:
(1) Your company is factory or Trade Company?
Answer: We are professional low oil consumption diesel generator sets manufacturing factory.
(2) Your diesel generator power range?
Answer: Now we mainly produce QS series 8-3000kva brushless alternators.
(3) Which brand Electrical Generator you produce?
Answer: Now we produce USA Cummins brand Electrical Generator, Sweden Volvo Generator, Korea Doosan diesel generator, German Deutz Electrical Generator, and China local brands' generator.
(4) Where is your main market?
Answer: We mainly export Electrical Generators to southeast Asia, central Asia, the Middle East, Africa and South America
