Rated frequency (Hz): 50 60
Rated voltage (V): 230 240/120
Rated current (A): 18.3 19.2/38.4
Rated output power (KVA): 4.2 4.6
Rated rotation speed (rpm): 3000 3600
DC output: 12V 8.3A
Power factor (cosφ ): 1.0
Phase number: Single phase
Noise level [dB(A)@7m]: 84-85
Overall dimension (L*M*H)[mm(in)]: 660*470*565 (25.98*18.50*22.24)
Dry weight [kg(lbs.)]: 100(220)
Structure type: Open-frame type
Excitation mode: Self-eacitation and constant voltage(AVR)
Engine model: SH186F/E
Engine type: Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine
Displacemen [ml]: 406
Compression ratio: 19: 1
Rated power [KW(Hp)/rpm]: 5.7(7.64)/3000 6.3(8.45)/3600
Starting system: CL: Recoil starter E: Electric starter
Rotation dircetion (View from flywheel): Clockwise
Fule: 0#(summer)-10#(winter) light diesel oil
Lube: SAE10W30 (above CC grade)
Low oil pressure alert system: With
Branch manfachurer: Taizhou Haofeng Industrial &Commercial Co., Ltd.
A manufacturer specializing gasoline generator, diesel generator, gasoline water pump, gasoline chain saw, gasoline cut-off saw, gasoline brush cutter, gasoline hedge timmer.
With ISO9000, CE, EPA, ROSH.
