| Prod Model: |
DG10LN/ DG10LN-3P/DG12LN/DG12LN-3P |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Optional |
| Cooling Method: |
Water Cooling |
| Stroke: |
Four Stroke |
| Installation Method: |
Portable |
| Type: |
Basic Diesel Generator |
| Output Type: |
AC Three Phase |
Product Description
Spec.
Model: DG10LN DG10LN-3P DG12LN DG12LN-3P
Frequency (Hz): 50/60 50/60 50/60 50/60
Rate power (kW): 8/ 9 8/9 8.8/10 8.8/10
Max. Power (kW): 8.8/10 8.8/10 9.7/11 9.7/11
Voltage(AC): 115/230V
Speed(rpm): 3000/3600
Power factor: 1.0 0.8 1.0 0.8
Starting way: Electric starting
Weight(Kg): 165 165 165 165
Engine model: CT286FE CT286FE CT286FE CT286FE
Type: 2-cylinder, V-type, 4-stroke, air-cooled, direct-injection
Bore* stroke(mm): 86*70
Displacement (L): 0.812
Output power(kw): 11.76
Fuel consumption: ≤ 298/kw. H
Rotation direction of output shaft: Counter-clockwise
Lubricating way: Splashing, pressure
Cooling way: Forced air-cooled
Capacity of lube oil (L): 1.7L
|
Model |
DG10LE |
DG15LE |
DG20LE |
DG25LE |
DG30LE |
DG40LE |
DG50LE |
|
GENERATOR Frequency(HZ) |
50/60 |
50/60 |
50/60 |
50/60 |
50/60 |
50/60 |
50/60 |
|
Rated output(kw/kva) |
10/12.5 |
15/18.75 |
20/25 |
25/31.25 |
30/37.5 |
40/50 |
50/62.5 |
|
Rated voltage(v) |
400/230 |
400/230 |
400/230 |
400/230 |
400/230 |
400/230 |
400/230 |
|
Power factor(cos) |
0.8 |
0.8 |
0.8 |
0.8 |
0.8 |
0.8 |
0.8 |
|
Rated currency(A) |
18.14 |
27.1 |
36.3 |
45.2 |
54.1 |
72 |
90 |
|
Phase |
3-Phase 4-wire |
3-Phase 4-wire |
3-Phase 4-wire |
3-Phase 4-wire |
3-Phase 4-wire |
3-Phase 4-wire |
3-Phase 4-wire |
|
Starting system |
Electirc |
Electirc |
Electirc |
Electirc |
Electirc |
Electirc |
Electirc |
|
ENGINE Model |
295D |
495D |
495D |
4100D |
4100ZD |
4105D |
4105D |
|
Cylinder Number: |
3 |
4 |
4 |
4 |
4 |
4 |
4 |
|
Displacement |
4.33 |
6.49 |
6.49 |
7.01 |
7.52 |
4.33 |
4.33 |
|
Borexstroke(mm) |
85x125 |
85x125 |
95 x125 |
100x105 |
102x118 |
105x118 |
105x118 |
|
DIMENSION Dimension(LxWxH)(mm) |
1560*820*990 |
1660*820*990 |
1660*820*990 |
1660*820*990 |
1660*820*990 |
1950*850*1250 |
1950*850*1350
|
