North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Inner Diameter:
190.5 Mm
Outer Diameter:
203.2 Mm
Width:
6.35 Mm
Weight:
0.154 Kg
Rolling Body:
Ball Bearings
The Number Of Rows:
Single
Outer Dimension:
Large (',200-430mm)
Load Direction:
Radial Bearing
Material:
Bearing Steel
Separated:
Unseparated
Product Description
Our company is a professional enterprise engaged in the production of thin-wall bearings. The inner diameters of the bearing sizes range from 20 mm to 1500 mm. There are large number of products such as 6700 series, 6800 series, 6900 series, 160 series, 60 series available in a long term.
We have all kinds of bearing products, for example. Thin-wall deep groove ball bearings, thin-walled angular contact ball bearings, angular four- point contact ball bearings, excavator special bearings. Precious standard:
The accuracy control level of this series of bearings can be: P0, P5, P6, P4 The vibration and noise control level of the bearings can be Z1V1, Z2V2, Z3V3. These series of bearings can meet all kinds of industrial needs.
Deep groove ball bearings can withstand radial load and two-way axial load, making it very suitable for high speed rotation and requiring low noise, low vibration.
Main Application: Car: Rear wheel, transmission, electrical equipment parts Electric: General motor, household electrical appliances Other: Instrumentation, internal combustion engines, construction machinery, railway vehicle, loading and unloading handling machinery, agricultural machinery, all kinds of industrial machinery.
Type
Major dimensions
weight
Rated loading
Limiting speed
equivalent
d
D
B
radial
thrust
static
dynamic
static
dynamic
SILVERTHIN
IN
MM
IN
MM
IN
MM
KG
Co(N)
Cr(N)
Co(N)
Cr(N)
(RMP)
KAA10CLO
1
25.4
1.375
34.925
0.1875
4.763
0.014
1510
1470
4310
4270
16840
SAA10CLO
KAA15CLO
1.5
38.1
1.875
47.625
0.1875
4.763
0.018
2140
1690
6140
4890
11850
SAA15CLO
KA020CPO
2
50.8
2.5
63.5
0.25
6.35
0.045
3510
29360
10140
7700
8890
SA020CPO
KA025CPO
2.5
63.5
3
76.2
0.25
6.35
0.059
4270
2850
12370
8270
7270
SA025CPO
KA030CPO
3
76.2
3.5
88.9
0.25
6.35
0.068
5070
3020
14630
8810
6150
SA030CPO
KA035CPO
3.5
88.9
4
101.6
0.25
6.35
0.082
5830
3200
16860
9210
5330
SA035CPO
KA040CPO
4
101.6
4.5
114.3
0.25
6.35
0.086
6630
3340
19130
9700
4710
SA040CPO
KA042CPO
4.25
107.95
4.75
120.65
0.25
6.35
0.091
7030
3430
20240
9960
4440
SA042CPO
KA045CPO
4.5
114.3
5
127
0.25
6.35
0.1
7380
3470
21400
10050
4210
SA045CPO
KA047CPO
4.75
120.65
5.25
133.35
0.25
6.35
0.104
7780
3560
22510
10280
4000
SA047CPO
KA050CPO
5
127
5.5
139.7
0.25
6.35
0.109
8180
3600
23620
10500
3810
SA050CPO
KA055CPO
5.5
139.7
6
152.4
0.25
6.35
0.113
8990
3690
25890
10720
3480
SA055CPO
KA060CPO
6
152.4
6.5
165.1
0.25
6.35
0.127
9740
3830
28110
11120
3200
SA060CPO
KA065CPO
6.5
165.1
7
177.8
0.25
6.35
0.136
10540
3960
30380
11480
2960
SA065CPO
KA070CPO
7
177.8
7.5
190.5
0.25
6.35
0.141
11300
4000
32650
11570
2760
SA070CPO
KA075CPO
7.5
190.5
8
203.2
0.25
6.35
0.154
12100
4090
34870
11830
2580
SA075CPO
KA080CPO
8
203.2
8.5
215.9
0.25
6.35
0.172
12860
4270
37140
12320
2420
SA080CPO
KA090CPO
9
228.6
9.5
241.3
0.25
6.35
0.2
14410
4400
41640
12720
2160
SA090CPO
KA100CPO
10
254
10.5
266.7
0.25
6.35
0.227
15970
4580
46130
13340
1950
SA100CPO
KA110CPO
11
279.4
11.5
292.1
0.25
6.35
0.236
17530
4770
50620
13790
1780
SA110CPO
KA120CPO
12
304.8
12.5
317.5
0.25
6.35
0.254
19080
5020
55110
14230
1630
SA120CPO
