Product Description
Engine
Power Model CC188-LPG
Power Type Single Cylinder, 4-stroke, OHV, Bore× Stroke(mm) 88X64
Displacement(CC) 389
Starting Mode Recoil Starter, Recoil/Electric Starter
Sound level @ 7 meter,
Full Load (dB) 77
Lube Oil Capacity(L) 0.9
Lube Oil Type SAE10W-30, <4° C; SAE10W-40, >4° C
Fuel Consumption (Rated Power) LPG: 0.32kg/kwh
Rated Engine Power(kW) LPG: 7.6/3600
|
Generator |
|
Generator Model |
Single-Phase Synchronous Brush Alternator |
|
Power Factor(cosφ) |
1.0/0.8 |
|
Excitation |
Self-excitation |
|
DC Output |
12V/8.3A |
|
Voltage Adjustment System |
Automatic Voltage Regulator |
|
Generator |
Revolving Field |
|
Adjustment Rate of Steady Voltage |
≤±5% |
|
Adjustment Rate of Steady Frequency |
≤±5% |
|
Insulation Resistance(Cold State) |
≥200MΩ |
|
Connecting Mode |
Power Shaft Rigid Coupling |
Chenchang Greenpower is a high-tech developer and producer of gasoline/gas engines, generator, and other power equipments. The
