| Prod Model: |
LHDG400 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model Number: |
Lhdg400 |
| Brand Name: |
Lvhuan |
| Engine Type: |
Z12V190bc--1 |
| Prime Power/Standby Power: |
320kw/400kw |
| Rated Speed: |
1500r/Min |
| Rated Frequency: |
50Hz |
| Rated Voltage: |
400V/230V |
| Phase: |
AC 3-Phase, 4 Wire |
| Oil Consumption: |
≤1.6g/Kw.H |
| Fuel Oil Consumption: |
≤209.4 |
| Type: |
Basic Diesel Generator |
| Installation Method: |
Portable |
| Stroke: |
Four Stroke |
| Cooling Method: |
Water Cooling |
| Output Type: |
AC Single Phase |
Product Description
190 series diesel engine is a kind of high speed and powerful diesel engine with good quality and wide applications.with continuous improvement and adoption of the technology result of modern internal-combustion engine, this engine possesses characters of advanced technique, compact in structure, speedy start, easy to operate, convenient to maintain and suitable to work in harsh environment,etc.
for 190 series genset, we adopt the 190 series as power matching alternator with high quality and high efficiency. the power ranges from 400 kw to 1000kw, and can be built into a power station with two gensets or more than two gensets.
Model Number
|
LHDG400
|
Brand Name
|
LVHUAN
|
Engine Type
|
Z12V190BC--1
|
Prime power/Standby power
|
320KW/400KW
|
Rated Speed
|
1500r/min
|
Rated Frequency
|
50Hz
|
Rated Voltage
|
400V/230V
|
Phase
|
AC 3-Phase, 4 wire
|
Oil consumption
|
≤1.6g/kw.h
|
Fuel Oil consumption
|
≤209.4
|
Engine Capacity
|
71.45 L
|
Cylinder Number
|
12 V
|
Cylinder Bore
|
190mm
|
Stroke
|
210mm
|
Starting System
|
air motor & electric motor
|
Cooling method
|
water cooler
|
Lubricant method
|
Passive and splashing lubricant
|
Isolation class
|
H
|
Protection
|
IP23
|
Alternator
|
Siemens
|
Power Factor
|
0.8 lagging
|
Exciting method
|
brushless
|
Colour
|
your choice
|
Certificates
|
ISO 9001:2008, CE
|
Warranty
|
1 year or 1500 running hours
|
Type
|
Open
|
Control system
|
Automatic alarm system
|
Our Service
1.pre-sale service:
(1)We will send our engineer to prospect the site of power station free to charge.
(2)According to the situation of site we can supply you many drawings:like power station floor plan,engineering flow sheet of circle cooling system,genset installation,genset foundation,electrical connection and some other techincal support etc.
2.Sale service:
(1)we will send our engineer to the site to guide you the installation of generator set, subsystem and relative equipment.
(2)We will debug the generator set till it can generate power successfully.
(3)We will also supply a technical training to the operators.Orcan send your staff to our company.We can train you till you can operate the generator set.
3.After-sale service:
(1)Our every engineers are in charge of different area,we will response periodically and support you technical service free of charge,
(2)For the quality problem, we will service for you free of charge during the guarantee period.
(3)One year guarantee period and lifetime service.
(4)we solve quality problem in time when genset doesn't work,We insure to help our clients to gain the biggest economic profit.
FAQ
1.How to choose the right model?
A: It depends on real output power, Voltage, Frequency and gas type.
2.What is the oil consumption and capacity per hour?
A: 1.0-1.63g of lubricant oil consumption per hour. 1.0 Cubic meter gas can produce 1.5-3.0kw/h power. The capacity depends on gas energy. E.g 1.0 Cubic meter natural gas produce about 3.0kw/h
3.What is the overhaul?
A: About 30000 working hours. A week is enough to finish.
4. What is the warranty?
A: 1 year. Inside this 1 year, we offer all spare parts free of charge. After this period, spare parts are not free. But, a set of spare parts will be shipped together with machine free.
5. How is the service?
A: We offer installation,repair and maintain service abroad. And online guide service if needed anytime. Our before-sale, in-sale and after-sale service are all trustable, you can name it.
Please feel free to ask question and quotation.
Our advantage:
a.Strong technology research and development team
b.Strong sales team
c.Factory area of vast
d.Ever export many country in the world, we have many case of succesfully
e. The best quality service
Shandong Lvhuan Power Equipment Co., Ltd. is a manufacturer which specially produces internal-combustion gas engine generator sets and gas engines, with registered capital of more than RMB10 million, annual turnover of RMB100 million, over 200 staff, beautiful scenery and convenient transportation. Our factory mainly specializes in the design, research, production, sale, installation and technical service of gas generator sets and diesel generator sets. Our company has strong specialty, powerful technical force, a complete production plant, advanced processing technology, mature inspection method and a strict test system.
Our products include 105, 135 and 190 series base engines. The output power ranges from 10kw to 500kw. The gensets can be used for biogas, natural gas, oil associated gas, coal mine gas and mash gas produced by burying rubbish and sewage disposal.
We manage our company by ISO9001 system strictly. Gas engines and alternators are environment-friendly products.
Our philosophy is "Only pay attention to supplying stronger power to you". More importantly, combining with our continuous technological innovation and hard work, we believe that you will choose our company and keep a long-term business relationship with us!
