| Prod Model: |
HCD3700TS |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| OEM: |
Yes for 3kw Silent Diesel Generator |
Product Description
The specification of 3KW single phase silent diesel generator as below:
|
Model |
HCD3700TS |
|
Frequency (HZ) |
50 |
60 |
|
Rated Output (KVA) |
2.8 |
3 |
|
Maximum Output (KVA) |
3 |
3.2 |
|
Rated Voltage (V) |
115/230 |
120/240 |
|
Rated current (A) |
24.4/12.2 |
25/12.5 |
|
Rated rotation speed (rpm) |
3000 |
3600 |
|
Phase No. |
Single phase |
|
Power Factor |
1.0 |
|
Excitation Mode |
Self-excitation, 2 pole and constant voltage (AVR) |
|
Panel Type |
General Panel |
|
DC Output |
12V./8.3A ,Terminal Post |
|
Structure Type |
Soundproof |
|
Noise Level (7m) dB(A) |
72 |
|
Engine Model |
HC178F |
|
Engine type |
Single-Cylinder, Vertical, Four-Stroke, Direct Injection,Air Cooled Diesel |
|
Bore × Stroke(mm) |
78 x 62 |
|
Displacement (L) |
0.296 |
|
Rated Power KW |
3.68/3000 |
4.0/3600 |
|
Fuel comsumption Rate(g.kw/h) |
276.1 |
285.6 |
|
Compression Ratio |
20:01 |
|
Lubrication System |
Pressure Splashed |
|
Starting System |
Electric Start with 30Ah MF battery |
|
Fuel Type |
0#(summer)-10#(winter)-35#(chilliness) diesel |
|
Lube Oil Brand |
SAE10W30 (above CD Grade) |
|
Lube Capacity (L) |
1.1 |
|
Fuel Tank Capacity (L) |
15 |
|
Continuous Running Time (hr) |
12 |
|
Overall Dimension: LxWxH (mm) |
955 x 560 x 780 |
|
Dry Weight (Kg) |
140 |
|
Quantity in 20FT |
72 Pcs |
|
Optiomal Features: |
|
ATS |
Optional |
|
Digital Panel |
Optional |
|
Remote control |
Optional |
|
We reserve the right to change specifications without notice |
