Cooling Method:
Wind Cooling
Stroke:
Four Stroke
Installation Method:
Portable
Type:
Micro-Computer Control Automatic Diesel Generator
Product Description
HD3600D
DC-Generator
MODEL
HD3600D
Type
Permanent magnet, brushless, bearing-less
Voltage Regulate
Automatism electronic regulate
Rated Dc Output
3.0KW
Max Dc Output
3.6KW
Voltage output regulation
0.5-1.0VDC
Ripple quotiety
150mV (when connecting on the battery)
Rated Dc Voltage
12/24/36/48V
Rated Current
200/110/72/55A
Run output Dc Voltage
14.5/28/39/52.5V
Diesel Engine
Model
HD178FA
Type
Forced Air-cooled, 4-Stroke, Vertical diesel
Bore× Stroke
78× 62mm
Air cleaner
Semi-dry double silent type
Cooled way
Air-cooled
Displacement
296ml
Compression ratio
20: 01
Combustion system
Direct injection
lubricating oil
SAE10W30 ((CC )
lubricating oil capacity
1.65L
Lubrication system
Pressure Splash
Power output
8.6HP/3600(HP/ rpm)
Fuel consumption
≤ 283
DC-Generator-Set
Fuel
0# (summer) -10# (winter) Diesel oil
Starting system
hand-operated/Electric start
Noise level
75-80(7m)dB(A)
Oil alarm
No lube oil Auto stop safekeeping
continuous operating
9h
Fuel capacity
12.5L
Front panel control system
One-DC Output Socket, DC Output Pilot lamp, Over loading protect& Malfunction Pilot lamp
Dimension L× W× H
700× 480× 570mm
Gross/ Net weight
61/64kg
Unit(20FT)
130
Established in July 2007, located in Weiyang district of Yangzhou, a city subordinate to Jiangsu province, Yangzhou Hengdong Mechanical & Electrical Co., Ltd is conveniently suited near freeway with ascendant investment environment. It arranges a settlement of 50 employees, among which there are 30 boasting academic certificate at or above the junior college level or obtaining junior superior title. Most of 8 technicians have served as Chief Engineer or Assistant Chief Engineer in the well-known generator manufacturing enterprises.
The company owns international advanced product research and development center, assembly line, machine performance test line, and generator component test table, which are all provided with computer-control system. Its leading product, HD power brand generators, can be widely applied in the home power solution, cars industry, army connection system, network system and telecom area.
Until now, with the certification of ISO9001, EPA, CARB and CE, the company has provided its products to a lot of different market which includes North & South America, Europe, Africa, Middle-east and Chinese local market.
Hengdong is not only an OEM factory, but also the strong backing of its client who researches and develops new suitable products every year for the ever-changing world wide market. We will be always keep going on improving the product value and creating long time partnership with all our world wide strategic partners.
