| Prod Model: |
10kva |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Generator Alternator: |
Brushless with AVR |
| Generator Controller System: |
Auto Start/Auto Stop/Parallel Running |
| Generator Cylinder: |
3 |
| Generator 100% Fule Consumption: |
13L/H |
| Generator Noise: |
≤ 80 |
| Generator Engine: |
Yd385g |
| Generator Starting: |
Electric |
| Generator Fuel Tank: |
Yes |
| Stroke: |
Four Stroke |
| Type: |
Basic Diesel Generator |
| Cooling Method: |
Water Cooling |
| Installation Method: |
Fixed |
| Output Type: |
AC Three Phase |
Product Description
We are the professional generator manufacturer with OEM factory in Guangzhou
Many style generators in stock 10kVA, 12kVA, 15kVA, 20kVA, 25kVA, 30kVA, 40kVA available
1. Description of Products
| Generator Set Model | CDY-8kw/10kva |
| Generator Set Power | 8kw/10kva |
| Generator Powered by Yangdong Engine |
| Diesel Engine Model | YD385G |
| Engine Characters | Water-cooled, in line, 4-cYDle, direct injection, 1500rpm |
| Bore x Stroke (mm) | 85x90 |
| Rated Output | 11kw/13.75kva |
| Fuel Consumption (g/kw.hr) | 262 |
| Lube Consumption (g/kw.hr) | 2.72 |
| Compression Ratio | 18 |
| Starting | Electric (12V) |
| ALTERNATOR MODEL | Newage Stamford PI044E or Leadtech LTG164B |
| Rated Power | 8kw/10kva brushless with AVR |
| Voltage (V) | 220/380V 230/400V 240/415V 127/220V |
| Current (A) | 14 |
| FreYuency (Hz) | 50 |
| Power Factor | 0.8 |
| Brush/Brushless | Brushless |
| Dimensions (LxWxH) mm | S: 1700x960x1060 |
| Gross Weight (KGS) | 600 |
| 20FT | 12 PCS |
| Controller | Smartgen 6110 or Deepsea 7320 |
| Standard | Muffler |
| Battery 80A*1 |
2.After-sales Service
1 year or 1800 running hours subject to the earlier one.
24 hours after-sales contact number: 0086 18520604611
3.Terms of Payment
1.)T/T
2.)Western Union
3.)Cash
4.Trade Terms of Products
| Generator Warranty | 1800 hours or 1 year subject to the ealier one. |
| Delivery Items | FOB,CNF,CIF,EXW,Delivery Guangzhou |
| Delivery Time | 15-20 days after receiving advanced payment. |
| Generator MOQ | 1PCS |
| Package | PE Film+Pearl Wool+Iron Frame (standard export packing) |
| Certificate | SGS;Cummins Authorized Factory;TUV;Soncap |
| Port | Guangzhou,Shenzhen,Shanghai |
| Payment | T/T Cash or Western Union |
| Please give detail needs in your inquiry, so that we can make power solutions for you. |
Features of Gen.set powered by China Yangdong Engine (China engine):
1.12 months parts warranty service
2.Short delivery time, as we always have Yangdong engine in stock
3.Spare parts are easy to get from worldwide market with much cheaper price
4.Perfect after-sales service network
5.Both 50HZ @1500rpm and 60HZ@1800rpm are available
6.Rigorous test including 50% load,100% load and 110% load
7.Stronger power with affordable price
8.China good brand engine
Standard configuration of China Yangdong generator design:
1.Original engine
2.Alternator coupled with Stamford alternator, copy Stamford alternator
3.Soundproof canopy, Super silent, open frame, Trailer mounted, Containerized
4.Controller Smartgen 6110
5.Circuit breaker CHNT
6.Base fuel tank 8 hours continuous running for soundproof type, 24 hours continuous running for super silent type.
7.Free-maintenance battery with Auto Battery Charger
8.Industrial silencer each 2 PCS per set with flexible exhaust hose.
Generator
1. Open type or silent type (soundproof type), Super Silent
2. Generator powered by Engine: Cummins, engine, Lovol, Deutz, WeiChai, Yangdong, ISUZU
3. Alternator: Stamford, Marathon, Leroy Somer etc
Generator Rated output: 5kVA - 2000kVA
Rated frequency 50/60 Hz
Rated voltage 230/400V, 220/380V, according to customers
Power factor: 0.8(lag)
Super Silent type Noise level at 7m ≤ 65DB
Excitation Mode: (Brushless) Self-excitation and constant voltage (AVR)
Starting system: Electric start 12V/24V
Protection System: High water temperature protection, Engine oil alarm, Over load Protection
Overfrequency protection, Emergency stop
Control System: Digital Control Panel; Meter Panel
Option: ATS, AMF, Trailer, Container
Our Diesel Generator Set Production Range is as follows:
Engine (motor) for Choice
1. Cummins (USA ) 20kVA - 2000kVA
2. Deutz (Germany) 20kVA - 150kVA
3. (UK) 8kVA - 2000kVA
4. ISUZU (Japanese) 20kVA - 40kVA
5. Lovol (China) 20kVA - 150kVA
6. Yangdong (China) 8kVA - 50kVA
7. Weichai (China) 8kVA - 150kVA
8. Shanghai Engine
9. Yuchai Engine
10. KUBOTA Engine 10kVA - 50kVA
Canopy for Choice
1. Silent type (75- 80 dB(A) at 7 meters)
2. Super Silent type (65-70 dB(A) at 7 meters )
3. Open type
4. Trailer type (mobile)
5. Container Type
6. Parallel System
* Alternator for Choice (brushless with AVR)
1. Stamford Newage
2. Leroy Somer
3. Marathon
4. Leateck
Good Reasons Why you Source JIUAN Generator
1)Professional Generator OEM factory in Guangzhou
2) 14 years experience in generator and exporting
3) 5Th year gold supplier in Alibaba
4) Products lines verified by professional inspectors
5) High quality products at affordable prices
6) Place orders safety
7) All engines are brand new and original - Credible
Guangzhou Jiuan Mechanical & Electrical Co., Ltd. is a professional generator manufacturer and exporter with generator capacity from 2kVA to 2000kVA. Generator can be powered by Cummins, Perkins, ISUZU, KUBOTA and Chinese engine. Welcome to chose our products and don' T hesitate to contact us.
Our Diesel Generator Set Production Range is as follows:
* Engine (motor) for Choice
1. Cummins (USA ) 20kVA - 1500kVA
2. Perkins (UK) 8kVA-1000kVA
3. Deutz (Germany) 20kVA - 150kVA
4. ISUZU (Japanese) 20kVA - 40kVA
5. Kubota (Japanese) 7kVA-50kVA
6. Lovol (China) 20kVA - 150kVA
7. Yangdong (China) 8kVA - 40kVA
8. Weichai (China) 8kVA - 150kVA
9. Shanghai Engine
10. Yuchai Engine
* Canopy for Choice
1. Silent type (75- 80 dB(A) at 7 meters)
2. Super Silent type (65-70 dB(A) at 7 meters )
3. Open type
4. Trailer type (mobile)
5. Container Type
6. Parallel System
* Alternator for Choice
1. Stamford
2. Leroy Somer
3. Marathon
* Controller
1. Smartgen
2. Deepsea (UK Brand and imported)
