Size:
1480*780*1050
Engine Brand:
Yangdong (Yd380d)
Prime Power:
10kVA/8kw
Alternator:
Jdg164c
Frequency:
50Hz (1500rpm)
Voltage:
220V
Phase:
1
Control Panel:
Smartgen 410
Installation Method:
Fixed
Stroke:
Four Stroke
Cooling Method:
Water Cooling
Output Type:
AC Three Phase
Product Description
Specification of generator set Generator model GDYD8*S Prime power:10kva/8kw Rated voltage:220v Rated frequency:50HZ Rated speed:1500
Engine brand:Yangdong Engine model:YD380D control panel smartgen 410 Mute decibels:about 65 Fuel consumption:220g/kwh Fuel tank volume:40L Emission levels:3.707 Speed governor electronic Cooling system forced water cooling cycle Alternator brand :copy stamford Model:JDG164C Number of phase:1 Number of bearing:1 Protection grade:ip23 Exciter type brushless ,self exciter ,AVR automatic voltage regulation ,100% copper winding wire Instruction: class H
We take this machine to 116th canton fair ,all the data is real and accurate. we start it at the fair,attract many buyers.
Inspection and test 1. Each engine shall be tested at manufacturers workshop to certify the engine output and fuel consumption in accordance with the site operating condition specified by purchaser on the specification datasheet. 2. All relevant information drawings pertinent to the testing and test procedure shall be transmitted to the purchaser in advance of the test date notification. 3. The engine and generator shall be tested separately in accordance with relevant standards specified above. 4. The completed and individually tested engine and generator shall be assembled onto the baseplate with all auxiliaries, instruments and controls for a complete test of the generator set.
Established in Year 2006, GODLIKE POWER is headquartered in Yangzhou city, Jiangsu Province, only 2.5 hrs far from Shanghai or Nanjing. It has grown into a leading manufacture of diesel generators&alternators in China and ranked amongst the top manufacturers worldwide.
Motivated by our slogan to provide "Excellent Power Solution", Godlike Power focuses on design, manufacture, sales, installation and service of diesel generators&alternators. Our diesel generators range from 8 kVA to 2500 kVA, equipped with Perkins, Cummins, Mitsubishi, Doosan, Deutz, MTU etc and equipped with our alternator, Stamford, Leroy-Somer etc alternators as required. Our Stamford type brushless alternators range from 8kVA to 1250kVA, 50Hz/60Hz option, rpm 1500-1800, voltage 110V-690V, class H, IP23, all easily coupled with Industrial & Marine, Diesel & Gasoline engines.
GODLIKE people treat Quality and Service as enterprise's life, and has competitive advantages.
GODLIKE generators are being exported to Europe, America, Southeast Asia, the Middle East, South Africa, and many other countries and regions, obtaining great corporate reputation and long-terms partner cooperations.
