Vacuum swing adsorption (VSA) is a non-cryogenic gas separation technology.
Using special adsorbents-zeolites, VSA segregates certain gases from a gaseous mixture under minimal pressure according to the species' molecular characteristics and affinity for the adsorbents. These adsorbents (e. G., zeolites) form a molecular sieve and preferentially adsorb the target gas species at near ambient pressure. The process then swings to a vacuum to regenerate the adsorbent material.
Our JLOX product is specially developed for VSA oxygen concentration.
|
Property |
Unit |
Bead |
Note |
|
JLOX-100 |
JLOX-101 |
JLOX-102 |
JLOX-103 |
|
Diameter |
mm |
1.6-2.5 |
0.4-0.8 |
0.8-1.3 |
1.3-1.7 |
|
N2 Adsorption Capacity |
NL/kg |
≥ 19.5 |
≥ 19.5 |
≥ 19.5 |
≥ 19.5 |
1 bar, 25º C |
|
Crush Strength |
N |
≥ 25 |
~ |
~ |
≥ 15 |
Average |
|
Bulk Density |
g/ml |
0.60-0.65 |
0.60-0.65 |
0.60-0.65 |
0.60-0.65 |
Settled |
|
Particle Ratio |
%wt |
≥ 97 |
≥ 95 |
≥ 95 |
≥ 95 |
Standard Sieve |
|
Water Content |
%wt |
≤ 0.5 |
≤ 0.5 |
≤ 0.5 |
≤ 0.5 |
KF |
Luoyang Jianlong Chemical Industrial Co., Ltd. is a professional producer specialized in Zeolite molecular sieve and sodium silicate synthesis and manufacturing. The product ranges from synthetic zeolite properties A, X and Y, activated Zeolite powder of Properties A and X to quick-dissolving sodium silicate powder. Meanwhile, the company can also provide customized product such as 3A-D, 4A-5, 5A-D, 13X-D and 13X-5 etc. In 2005, Jianlong newly introduced LSX, NaY and CuX to the market.
We hope we can provide a good service to vary industrial field and meet every customer's needs. Our principle is: Promise is Guarantee! In 2004, the company was assesed and registered by NQA against ISO9001/2000.
