We Supply CE approved 5kw wind turbine with Grid-connected type and grid-off type.
And A set 5kw wind turbine contains:
Generator +Blade+Tail+ Controller + Inverter + Free stand tower/Guy wire tower+ Accessories
Detail specification as followes:
Numbers of blade (P): 3
Materials of blade: FRP complex resin
Diameter of wind turbines (m): 5.8
Out-in (start) wind speed: 3.5
Out-out (outage) wind speed: 20
Rated wind speed (m / s): 10
Rated speed (rotate / minute): 200
Max. Wind speed (m / s): 40
Wind energy ratio (% ): 0.42
Generator: Permanent magnetic generator
Generator rated power (W): 5000
Max. Output power (W): 6500
Output voltage (V): 230
Rated current (A): 21.7
Type of off-course: Wind direct-ion is decided by tail
Type of limit speed: Stanting limited by automatic
Protect: Manual
Tower: 3 pipe cone
Altitude of tower (m): 10
Charging control: Automatic
Weight (KG): 1200
Power generation of years (kwh): 12500
Inverter power supply: Square wave or corrected wave
Battery: N200x18
Time of charging (h): 20
SRM Wind Power Company is a professional wind turbine generator manufacturer in China. Our company owns large number of professional wind generator technique manpowers. Advanced producing equipment and test appliance after 13 years of development, we have formed perfect service system include a blend of design, produce, installation, debugging, marketing and aftersale service, main produces minitype Horizontal and Vertical type wind generators, Hybria system.
