Wheel Bearing, Angular Contact Ball Bearing, Kc120aro, Auto Spare Part

Wheel Bearing, Angular Contact Ball Bearing, Kc120aro, Auto Spare Part
Price: US $ 0.1/Piece
Trade Terms: FOB,CFR,CIP
Min Order: 1/Piece
Pay Type: T/T,Paypal
Angular contact ball bearings

Contact Angle between ring and ball, standard of contact Angle is 15 ° , 30 ° , and 40 °
The larger the contact Angle is, the larger axial load capacity will be.
The smaller the contact Angle is, the more conducive the high-speed rotation will be.
Single-row bearing can withstand radial load and one-way axial load.
DB combination, DF combination, and double-row bearings can withstand radial load and two-way axial load.
DT combination is suitable for occasion, like one-way axial load is greater, and the lack of rated load for a single bearing.
High speed with ACH type bearings are mostly used for machine tool spindle, of which the ball diameter is small and numerous.
Angular contact ball bearings are suitable for high speed and high precision rotation.

Main Use:
Single-row: Machine tool spindle, high frequency motor, gas turbine, centrifugal separator, small car front wheel, differential pinion shaft
Double-row: Oil pump, roots blower, air compressor, all kinds of transmission, fuel injection pump, printing machinery.

Packaging & Delivery
Packaging details:
1, wooden boxes
2. Be oiled and wrapped with water-proof belt
3. Wooden pallets
4. According to customers requirement
Delivery Detail:
2-5 days for stock bearing, 40-60 days for future goods

Specifications
1. Reasonable price
2. Various types
3. Quick delivery
4. OEM service

Product Specification:
1. Series: Angular Contact Ball Bearing
2. Cage: Machined brass cage,
3. Material: GCr15/GCr15SiMn
4. Precision: P0
5. Quality: IS09001: 2000
6. Packing: Standard export packing & industry packing & according to clients' requirement.
7. Brand: LRZ
8. Origin city: Luoyang of China
9. MOQ: 2 pcs
10. Delivery term: FOB Shanghai port & CIF
11. Others OEM orders available

Type
Major dimensions
weight
Rated loadingLimiting speedEquivalent
dD     Bradialthrust
staticdynamicstaticdynamicSILVERTHIN
InMmInMminmmkgCo(N)Cr(N)Co(N)Cr(N)(RMP)
KC040ARO4101.64.75120.650.3759.5250.20411340627032740181504570SC040ARO
KC042ARO4.25107.9551270.3759.5250.21312050641034790185904320SC042ARO
KC045ARO4.5114.35.25133.350.3759.5250.21812720654036790189504100SC045ARO
KC047ARO4.75120.655.5139.70.3759.5250.22713430667038790193103900SC047ARO
KC050ARO51275.75146.050.3759.5250.26314150685040790197903720SC050ARO
KC055ARO5.5139.76.25158.750.3759.5250.26815300694044130201903400SC055ARO
KC060ARO6152.46.75171.450.3759.5250.28616680721048130208603140SC060ARO
KC065ARO6.5165.17.25184.150.3759.5250.30818060743052130214802910SC065ARO
KC070ARO7177.87.75196.850.3759.5250.33119220765055470221502710SC070ARO
KC075ARO7.5190.58.25209.550.3759.5250.35420600778059520226402540SC075ARO
KC080ARO8203.28.75222.250.3759.5250.38122020801063520231802390SC080ARO
KC090ARO9228.69.75274.650.3759.5250.42624550827070860240202130SC090ARO
KC100ARO1025410.75273.050.3759.5250.48127310864078870247801930SC100ARO
KC110ARO11279.411.75298.450.3759.5250.52629890911086250257101760SC110ARO
KC120ARO12304.812.75323.850.3759.5250.56732430955093590266001620SC120ARO
KC140ARO14355.614.75374.650.3759.5250.6893777010440108980281601390SC140ARO
KC160ARO16406.416.75425.450.3759.5250.7854306011270124330299401220SC160ARO
KC180ARO18457.218.75576.250.3759.5250.884840012040139720323801090SC180ARO
KC200ARO2050820.75527.050.3759.5250.98535101274015444034610980SC200ARO
KC250ARO2563525.75654.050.3759.5251220622801438019252040080790SC250ARO
KC300ARO3076230.75781.050.3759.5251456798901584023064045190660SC300ARO
Prod Model: KC120ARO
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Inner Diameter: 304.8 Mm
Outer Diameter: 323.85 Mm
Breadth: 9.525 Mm
Weight: 0.567 Kg
Rolling Body: Ball Bearings
The Number Of Rows: Single
Outer Dimension: Large (',200-430mm)
Load Direction: Radial Bearing
Material: Bearing Steel
Separated: Unseparated
