Luoyang lirui bearing Co. Ltd is a professional company engaged in the production of bearings, such as series of thin-wall deep groove ball bearing, angular contact bearing, four-point contact ball bearing.
There are three kinds of structure of Thin-wall bearing, such as ARO, CPO, XPO. Which are short for thin-wall angular contact series, thin-wall deep groove ball series 3. Thin-wall four-point contact ball series
We also specialize in the production of American KAYDON substitute precision thin section bearing, and Germany substitute thin section bearing, imported substitute bearing, and Japan NTN substitute precision thin section bearing.
Our company is a professional enterprise engaged in the production of thin-wall bearings. The inner diameters of the bearing sizes range from 20 mm to 1500 mm. There are large number of products such as 6700 series, 6800 series, 6900 series, 160 series, 60 series available in a long term.
We have all kinds of bearing products, for example. Thin-wall deep groove ball bearings, thin-walled angular contact ball bearings, angular four- point contact ball bearings, excavator special bearings.
Precious standard:
The accuracy control level of this series of bearings can be: P0, P5, P6, P4
The vibration and noise control level of the bearings can be Z1V1, Z2V2, Z3V3. These series of bearings can meet all kinds of industrial needs.
Four-point contact ball bearing can bear radial load and two-way axial load
A single bearing can replace the positive combination or the back combination of angular contact ball bearings.
They apply to pure axial load or synthetic load with larger axial load in it.
Contact Angle (alpha) will be formed when the bearing withstand axial load from any direction, so the ring can always be in contact with the ball in any online points
Main applicable cage: Copper alloy cutting cage
Main use: Aircraft jet engines, gas turbine.
Packaging & Delivery
Packaging details:
1, wooden boxes
2. Be oiled and wrapped with water-proof belt
3. Wooden pallets
4. According to customers requirement
Delivery Detail:
2-5 days for stock bearing, 40-60 days for future goods
Specifications
1. Reasonable price
2. Various types
3. Quick delivery
4. OEM service
Product Specification:
1. Series: Four-Point Contact Ball Bearing
2. Cage: Machined brass cage,
3. Material: GCr15/GCr15SiMn
4. Precision: P0
5. Quality: IS09001: 2000
6. Packing: Standard export packing & industry packing & according to clients' requirement.
7. Brand: LRZ
8. Origin city: Luoyang of China
9. MOQ: 2 PCS
10. Delivery term: FOB Shanghai port & CIF
11. Others OEM orders available
| Type | Major dimensions | weight | Rated loading | Limiting speed | equivalent |
| d | D | B | radial | thrust |
| static | dynamic | static | dynamic | SILVERTHIN |
| IN | MM | IN | MM | IN | MM | KG | Co(N) | Cr(N) | Co(N) | Cr(N) | (RMP) |
| KB020XPO | 2 | 50.8 | 2.625 | 66.675 | 0.3125 | 7.938 | 0.073 | 4850 | 3780 | 14010 | 10940 | 8650 | SB020XPO |
| KB025XPO | 2.5 | 63.5 | 3.125 | 79.375 | 0.3125 | 7.938 | 0.091 | 5960 | 4090 | 17170 | 11920 | 7110 | SB025XPO |
| KB030XPO | 3 | 76.2 | 3.625 | 92.075 | 0.3125 | 7.938 | 0.109 | 6890 | 4310 | 19880 | 12460 | 6040 | SB030XPO |
| KB035XPO | 3.5 | 88.9 | 4.125 | 104.775 | 0.3125 | 7.938 | 0.122 | 7960 | 4540 | 23040 | 13210 | 5250 | SB035XPO |
| KB040XPO | 4 | 101.6 | 4.625 | 117.475 | 0.3125 | 7.938 | 0.136 | 9070 | 4800 | 26200 | 13920 | 4640 | SB040XPO |
| KB042XPO | 4.25 | 107.95 | 4.875 | 123.825 | 0.3125 | 7.938 | 0.141 | 9560 | 4850 | 17580 | 14100 | 4380 | SB042XPO |
| KB045XPO | 4.5 | 114.3 | 5.125 | 130.175 | 0.3125 | 7.938 | 0.15 | 74730 | 4980 | 28910 | 14410 | 4160 | SB045XPO |
| KB047XPO | 4.75 | 120.65 | 5.375 | 136.525 | 0.3125 | 7.938 | 0.154 | 10630 | 5070 | 30740 | 14630 | 3950 | SB047XPO |
| KB050XPO | 5 | 127 | 5.625 | 142.875 | 0.3125 | 7.938 | 0.172 | 11120 | 5160 | 32070 | 14900 | 3760 | SB050XPO |
| KB055XPO | 5.5 | 139.7 | 6.125 | 155.575 | 0.3125 | 7.938 | 0.186 | 12190 | 5340 | 35230 | 15480 | 3440 | SB055XPO |
| KB060XPO | 6 | 152.4 | 6.625 | 168.275 | 0.3125 | 7.938 | 0.2 | 13300 | 5520 | 38390 | 16010 | 3170 | SB060XPO |
| KB065XPO | 6.5 | 165.1 | 7.125 | 180.975 | 0.3125 | 7.938 | 0.213 | 14230 | 5600 | 41100 | 16240 | 2940 | SB065XPO |
| KB070XPO | 7 | 177.8 | 7.625 | 193.675 | 0.3125 | 7.938 | 0.227 | 15350 | 5780 | 44300 | 16730 | 2740 | SB070XPO |
| KB075XPO | 7.5 | 190.5 | 8.125 | 206.375 | 0.3125 | 7.938 | 0.240 | 16460 | 5920 | 47460 | 17170 | 2560 | SB075XPO |
| KB080XPO | 8 | 203.2 | 8.625 | 219.075 | 0.3125 | 7.938 | 0.259 | 17530 | 6050 | 50620 | 17570 | 2410 | SB080XPO |
| KB090XPO | 9 | 228.6 | 9.625 | 244.475 | 0.3125 | 7.938 | 0.299 | 19570 | 6270 | 56490 | 18150 | 2150 | SB090XPO |
| KB100XPO | 10 | 254 | 10.625 | 269.875 | 0.3125 | 7.938 | 0.331 | 21750 | 6580 | 62810 | 19080 | 1940 | SB100XPO |
| KB110XPO | 11 | 279.4 | 11.625 | 295.275 | 0.3125 | 7.938 | 0.340 | 23800 | 6850 | 68680 | 19350 | 1770 | SB110XPO |
| KB120XPO | 12 | 304.8 | 12.625 | 320.675 | 0.3125 | 7.938 | 0.376 | 25980 | 7220 | 75000 | 20060 | 1620 | SB120XPO |
| KB140XPO | 14 | 355.6 | 14.625 | 371.475 | 0.3125 | 7.938 | 0.476 | 30070 | 7860 | 86740 | 21530 | 1400 | SB140XPO |
| KB160XPO | 16 | 406.4 | 16.625 | 422.275 | 0.3125 | 7.938 | 0.544 | 34300 | 8480 | 98970 | 22910 | 1230 | SB160XPO |
| KB180XPO | 18 | 457.2 | 18.625 | 473.25 | 0.3125 | 7.938 | 0.612 | 38520 | 9070 | 111160 | 24510 | 1090 | SB180XPO |
| KB200XPO | 20 | 508 | 20.625 | 523.875 | 0.3125 | 7.938 | 0.68 | 42750 | 9620 | 123350 | 26240 | 980 | SB200XPO |
Luoyang Lirui Bearing Co., Ltd, located in an ancient capital city Luoyang which is a great production base for bearing, is a new-high technology corporation with the integration of design, research and development, manufacturing. Our company is based on not only the development of China's bearing, but also the global perspective, and has first-class team of bearing experts and engineers, the domestic first-class CNC grinding, automatic equipment, and large-scale sophisticated equipment, all of these guarantee that our bearings have high precision and stability.
Our company has been found in 1994, since the establishment, we inherit "honest and trustworthy, the user orientated", adhere to high quality pre-sales technical support, superior product quality coupled with excellent after-sale service to serve every customer. We are specialized in the design, research and production to various non standard bearing, imported substitution bearing and special bearing, which are widely applied to aerospace, precision instruments, textile, precision lathe, port, mining, medical treatment, coal, cement, oil drilling, wind power generation, industrial robots, defense industry and other fields. A large number of our products are exported to the United States, Britain, Canada, Germany, Austria, Italy, Japan, Korea, Singapore, India, Pakistan, Thailand, Malaysia and other countries.
We have got ISO9001: 2000 certificate, as it is represented in "Quality Guideline", Lirui bearing focus on comprehensive quality management, and take it as a sustained effort to improve customer satisfaction. These requires our team including senior management take on the job training and further education. At the meantime, it is necessary to establish full assessment to ensure that this goes smoothly in this area. The company gradually forms a stable country and worldwide sales network. Each product reflects constant pursuit of the excellence of Lirui employees, and serves our customers by qualified products and business philosophy of "innovation, integrity and pragmatic, development". Creating value for customers and guarantee satisfaction to the customers are our principles, thus, we sincerely welcome friends from all over the world come to discuss, exchange and cooperation. Let us use our joint hands to create a bright future.
