Generator Permanent magnet direct drive AC generator
Rated power: 600W
Max power: 1000W
Rated rotor speed: 400r/m
Rated speed: 8m/s
Output voltage: 24V
Start up wind speed: 3m/s
Work speed: 3-25m/s
Security wind speed: 40m/s
Generator shell material: Pressure cast iron
Blades
Material of blades: FRP Lay-up by hand
Number of blades: 3PCS
Diameter of blades: 2.8M
Nose cone Material of dome: FRP Lay-up by hand
Number of dome: 1PCS
Tail Vane & Tail rob
Material: Q235 Steel plate
Surface treatment: Painting against decaying
Controller & Inverter
Rated output power of wind turbine: 600W
Max Solar panel input power: 200W
Rated output power: 600W
Output voltage: 220± 8%
Matched battery: 24V
Output frequency: 50± 2Hz
Working method: Continuous
Function: Charge and inverter
Application environment temperature: -10~40; Humidity: ≤ 80%
Over-load Capability: 150% 1 minute
Protection of over-load: 200% immediate protection
Voltage of resuming power-supply: 26± 1 (DC, V)
Stop charge DC voltage: 30± 1 (V)
Voltage of resuming charge: 24± 1 (DC, V)
Short-voltage protection: 20± 1 (V)
Stop working voltage: ≤ 18
Fuse current: 30 (A)
Guy wire tower
Height of pole: 6 m
Thickness: 4 mm
Tower diameter: 76mm
Flange: 125*125*8 mm
Material: Q235 Steel pipe
Surface treatment: Painting against decaying
|
HF-VAH-600W Vertical Axis Wind Generator |
|
Power |
600w |
Contact: :
Ricardo Suen |
|
Blades |
H-shaped |
|
Blades Number |
5 |
|
Rotor Diameter |
1.5 m |
|
Height of blades |
1.6 m |
|
Rated Rotated Speed |
400 r/m |
|
Start Up Wind Speed |
3m/s |
|
Rated Wind Speed |
8m/s |
|
Rated Power |
600W |
|
Output Voltage |
24v |
|
Operating Wind Speed |
3-25m/s |
|
Security Wind Speed |
40m/s |
|
Material of blades |
Glass Fiber Reinforced Plastic |
|
Tower Type |
Guy wire tower or Free stand tower |
|
Can Supply Power for |
Refrigerators, Washing machines, Water pumps, Cookers, Color television sets, Lighting, Electric fans, Charge |
Qingdao Hengfeng Wind Power Generator Co., Ltd is one of the leading wind turbine manufacturer in China. Company start at 2004, Workshop covers more than 5000 square meters. It is about 1 hour by car to Qingdao Airport. And 30 minutes to Qingdao port. The traffic is very convenient.
Our company mainly produces 150 watts to 100 kilowatts of small and medium horizontal axis, vertical axis wind turbines, wind and solar power supply system, widely used in off-grid and on-grid power generation system. Produced in strict accordance with the ISO9001 international standard production system management, we have standard production line and automated packaging line, strict product testing system, advanced test equipment, to ensure provide customers the highest quality products and services; All products have achieved CE certification. Hengfeng has unrivalled experience and has built up a global reputation for their robust and reliable performance.
Our products has been export to more than 60 countries, for example, Europe, Middle East, Southeast Asia, Australia etc; Widely applied for island, military, maritime monitor, home use, commercial business and remote area etc, we have integrated design, production, sale and after-sale service. If you are thinking about reducing your domestic energy bills or providing a multi-site energy solution for your business, HENGFENG can help achieve your renewable energy aspirations. We make sure that your wind turbine choice will work productively for you and deliver all-round environmental benefits.
