Vertical Axis Wind Generator
Power 300W 600W 1KW 2KW 3KW 5KW 10KW 20KW
Rotor diameter 1.8m 1.8m 2m 2m 3.2m 3.2m 3.2m 3.2m
Blades number 3 3 4 4 5 5 7 9
Blades length 1m 1m 1m 1m 1.6m 1.6m 1.6m 1.6m
Rated rotate speed 150(r/min) 150(r/min) 150(r/min) 150(r/min) 160(r/min) 160(r/min) 160(r/min) 150(r/min)
Rated wind speed 7-8m/s 7-8m/s 7-8m/s 7-8m/s 7-8m/s 7-8m/s 10-11m/s 12m/s
Star up wind speed 2m/s 2m/s 2.5m/s 2m/s 3m/s 3m/s 3m/s 3m/s
Working wind speed 3-24(m/s) 3-24(m/s) 3-24(m/s) 3-24(m/s) 3-24(m/s) 3-24(m/s) 3-24(m/s) 3-24(m/s)
Security wind speed 40(m/s) 40(m/s) 40(m/s) 40(m/s) 40(m/s) 50(m/s) 50(m/s) 50(m/s)
Rated power 300W 600W 1KW 2KW 3KW 5KW 1KW 21KW
The max power 350W 650W 1.5KW 2.5KW 4.5KW 6.5KW 1.1KW 21KW
Output voltage 220V 220V 220V 220V 220V 220V 220/110V 380V
The height of tower 8m 10m 10m 10m 10m 10m 10m 14m
The top part weight 49kg 63kg 73kg 78kg 98kg 102kg
Guy cable tower type 89*6 96*6 114*6 114*6 230*6 203*6 203*6 Steel(Q235B)
Output control system,
Charger control, inverter,
Charger control, inverter,
Charger control, inverter,
Charger control, inverter,
Charger control, inverter,
Charger control, inverter,
Charger control, inverter
Three-phase sine wave
Battery reference 12V100ah, 2PC 12V100ah, 2PCS 12V100ah, 4PCS 12V150ah, 4PCS 12V100ah, 18PCS 12V150ah, 18PCS 12V200ah, 30PCS 12V200ah, 60PCS
Yueqing Saibang Electric Co., Ltd. is a subordinate of saip electric group company limited, which is wholly invested by our group company. Depending on our group company's advanced technology and equipment introduced form developed countries, we have tremendous technical capabilities. Buondi mainly develops and produces new source products, including Solar Generator, Solar charge controller, Wind Generator, Solar Inverter, Solar tracking systems and so on.
