| Price: | US $ 185000/Set |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T,Paypal,Western Union |
Blades rotor Diameter (m) | 10/12m |
Material and number of the blades | FRB 3 PCS |
Rated power / max power (w) | 20k/25k |
Rated wind speed (m/s) | 12/9m/s |
Startup wind speed (m/s) | 3 |
Working wind speed (m/s) | 3-35 |
Survived wind speed (m/s) | 50 |
Rated rotation speed (r/min) | 150 |
Working Voltage (V) | DC240--500v |
Generator style | 3 phases, AC PMG |
Speed regulation method | Pitch controlled |
Stop method | Manual brake |
Working system | Off-grid working system/on grid working system |
Stand alone Tower height | 15m 18m |
| Prod Model: | FD12-20kw |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Power: | 20kw |
| Max Power: | 30kw |
| Working System: | Grid Tie/Grid off |
| Tower Height: | 15m-30m |
| Wind Turbine Type: | Horizontal Axis, Directly Drive, Variable Pitch |
| Rotating Shaft: | Horizontal |
| Stress Way Of Blade: | Lift Force |
| Number Of Blade: | Three Blade |
| Phase: | 3 Phrase |
| Certification: | IEC |
