Features:
1) Any permanent magnetic generators, providing invariable excitation on all occasions.
2) Easy to be connected with power network or other generators. Standard 2/3 pitches windings check excessive midline current.
3) Balanced rotor with single or two sealed ball bearings
4) Convenient installation and maintenance with easy access to terminals, rotating diodes and coupling bolts
Machines Features
Frame
All industrial standard is IP21, also IP23 is an option, but rates power will decrease 5%
Marine standard alternator is IP23, Air filter is an option, but rated power of the alternator will decrease 5% while it is installed.
Axis and Key
All of alternator rotors should pass balance test, whose vibrations are lower than the minimum of BS6861 P. 1, G 2.5 two bearing alternator has a half-key testing balance
Terminal and terminal box
The three-field alternator had 12 leads brought out to the terminals in the terminal box. The terminals are put on the non drive end. The box is equipped with removable panels.
Voltage regulation
Voltage regulation refers to the change of voltage from no-load to full-load with power factor ranging from 0.8 to 1 and 3%s fluctuation of the speed of engine. Voltage is adjusted via potentiometer of AVR
Option
1. Adapters and drive disks
2. Single phase.
3. Remote voltage adjust
4. IP23 enclosure
5. Space heaters
6. Thermistors.
Warranty policy
Guarantee for one year or 1200 hours whichever reach first from ex-factory date. During the guarantee period, YANAN will provide the free easy-damageable spare parts of alternator caused by our quality of production or raw material. After expiration, YANAN provides cost spare parts maintenance of alternator.
|
Model |
Rated Power (KW) |
Rated Current (A) |
Rated speed (r/min) |
eff(%) |
Cos |
Rated voltage (V) |
Regulate Volt. Adjust(%) |
|
TZH-10 |
10 |
18.1 |
1500 |
82.5 |
0.8 |
400 |
± 5 |
|
TZH-12 |
12 |
21.7 |
84.5 |
|
TZH-15 |
15 |
27.1 |
85.1 |
|
TZH-20 |
20 |
36.1 |
86.0 |
|
TZH-24 |
24 |
43.3 |
87.0 |
|
TZH-30 |
30 |
54.1 |
88.0 |
|
TZH-40 |
40 |
72.2 |
89.0 |
|
TZH-50 |
50 |
90.2 |
89.5 |
|
TZH-64 |
64 |
115 |
90.5 |
|
TZH-75 |
75 |
135 |
90.8 |
|
TZH-90 |
90 |
162 |
91.0 |
|
TZH-120 |
120 |
217 |
91.5 |
|
TZH-150 |
150 |
271 |
92.0 |
|
TZH-200 |
200 |
361 |
92.3 |
|
TZH-250 |
250 |
451 |
92.5 |
