CHARACTERISTICS: |
·LCD DISPLAY | Starting up can accumulate Max. 999999 times |
Using microprocessor as a core, Symbol LCD with backlight | ·Control protection: Automatic crank/stop of diesel engine, load |
Display, two languages display, key touch operation | Transfer(ATS control) and completely faults display protection |
·RS485 PORT | ·With ETS, idle control, pre-eat control, raises speed control |
Have a RS485 port with Modus communication protocol | Functions and all types of them are belong to relay output |
·Adapt to 3 phase- 4 wires, single phase-2 wires or | ·Parameters setting: Allow user to modify setting and store |
2 phase- 3 wires(120/240V), 50/60Hz AC power system. | Them by inside internal FLASH memory, the parameters can |
·Measure and display 3 phase voltage, 3 phase current, | Not be lost even with power off. All of parameters can be set |
Frequency, power, etc. Parameter of mains and gens: | Not only from the front panel, but by PC via SG72(an adaptor, |
MAINS GENS | USB-LINK-RS485) module; Or, through RS485 port via PC |
Line voltage(Uab, Ubc, Uca) Line voltage(Uab, Ubc, Uca) | ·Most of temperature, pressure, oil level sensor can be directly |
Phase voltage(Ua, Ub, Uc) Phase voltage(Ua, Ub, Uc) | Used, and also user can define sensor curve by themselves |
Frequency Hz Frequency Hz | ·Multiple crank disconnection conditions can be selected. |
| (Speed sensor, oil pressure, gens) |
LOAD | ·Power supply range is wide(8~35) VDC, accommodating to |
Power current(IA, IB, IC) Apparent power kVA | Different starting battery voltage environments |
Active power Kw Power factors Cos | ·All parameters use digital modulation, abandoning analog |
Inactive power kvar Accumulate total gens power kWh | Modulation using conventional electronic potentiometer, more |
·Mains have over voltage, under voltage, loss phase function | Reliability and stability |
; Gens have over voltage, under voltage, over frequency, under | ·Modular configuration design, Flame Retardant ABS plastic |
Frequency, over current function | Shell, inserted type connection terminals, flush type |
·Precision measure and display parameters about Engine, | Installation, compact structure, easy installation |
Temp. (WT), ºC/ºF both are display | |
Oil pressure(OP) kPa/Psi/Bar all be display | |
Fuel oil level(FL) %(unit) | |
Speed(SPD) RPM(unit) | |
Voltage of Battery(VB) V(unit) | |
Voltage of chargert(VD) V(unit) | |
Hour count(HC) can accumulate Max. 999999 hours | |
