90Watt Maximum power UL-70 UL-75 UL-80 UL-85 UL-90
Mono-crystalline solar paner
Features
@High conversion efficiency based on leading innovative photovoltaic technologies
@High stabillity with guaranteed+/-3%power output tolerance, ensuring return on investment
@Beautiful appearance
@Withstands high wind-pressure and snow load
@Easy to install
Quality and safety
@25-year power output warranty with China Pacific Property Insurance Co., Ltd
@Rigorous quality control meeting the highest international standards
@ISO9001: 2008(Quality Management System)certified factories manufacturing world-class products
Recommended Applications
@On-grid utility systems
@On-grid commercial systems
@Off-grid ground mounted systems
Characteristics UL-70 UL-75 UL-80 UL-85 UL-90
Open-Circuit Voltage(Voc) 21.45V 21.65V 21.85V 22.05V 22.25V
Optimum Operating Voltage(Vmp) 17.2V 17.4V 17.6V 17.8V 18V
Short-Circuit Current(lsc) 4.6A 4.81V 5.02V 5.21V 5.39V
Optimum Operating Current(lmp) 4.07A 4.31A 4.55A 4.78A 5A
Maximum Power at STC(Pmax) 70Wp 75Wp 80Wp 85Wp 90Wp
Operating Temperature -40oC to+85oC -40oC to+85oC -40oC to+85oC -40oC to+85oC -40oC to+85oC
Maximum System Voltage 1000VDC 1000VDC 1000VDC 1000VDC 1000VDC
Series Fuse Rating 11A 11A 11A 11A 11A
Power Tolerance ± 3% ± 3% ± 3% ± 3% ± 3%
Mechanical Characeteristics
Solar Cell Momo-crystalline 125× 125mm (5inch)
No. Of Cells 36(4× 9)
Dimensions 1210× 540× 35mm(47.6× 21.3× 1.4inch)
Weight 8.2kg(18.1lbs)
Front Glass 3.2mm(0.13inch) tempered glass
Frame Anodised aluminium alloy
Junction Box Cixi Renhe PV-rh06-70(TUV)
Temperature Coefficents
Nominal Operating Cell Temperature(Noct) 45± 2oC
Temperature Coefficient of Pmax -0.48%/oC
Temperature Coefficient of Voc -0.34%/oC
Temperature Coefficient of lsc -0.017%/oC
