Solar generator system LFS-MSP300, which is developed by our company. It can be used as home illumination as well as power supply for home digital products, TV, electric fan and so on. Especially suit for the families without electric supply or shortage of it.
Specification:
1) Solar panel: 100W/ 18V.
2) Battery capacity: 100Ah / 12V, Gel battery.
3) Inverter: 300W/220V power frequency inverter, Pure Sine-Wave.
4) Controller: 15A/12V, Multifunctions.
5) Load: AC 220V, DC 12V.
6) Output ports: AC 2 Line socket, DC Port.
7) The energy storage of MSP300 solar power system is about 1200Wh. That means it can basically ensure home illuminating and TV working for about 2 days after the battery had been full charged.
8) With 3 PCS of AC output port, you can plug your home TV or Fans to watch TV or cool your body, or plug fax machine or computer to work, or other digital / audio products.
M300 solar power system is able to convert the solar power to DC12V electric power which will then be stored into the storage battery. The DC12V electric power can also be converted to AC 220V/110V electric power when needed, then to power the electric equipments in your house such as illuminating light, TV, Audio, digital product, fax machine and computer, etc.
The energy storage of M300 solar power system is about 540Wh, that means it can basically ensure home illuminating and TV working for about 48 hours after the battery had been full charged.
When M300 solar power system is being charged, it can prevent overcharge, provide voltage and temperature compensation when stop charging, and cut down DC output of low voltage, etc. When M300 solar power system is inverting, it can provide overload protection, short-circuit protection, and temperature protection, etc.
The system is equipped with following functions:
Short-circuit protection;
Overload protection;
Overheating protection;
Prevent overcharge;
Prevent over-discharge;
Prevent reverse charge;
Protect function of revised connect between storage battery and solar panel;
Indicator light for LED lamp's charging and discharging;
Temperature auto-compensation;
Warnings:
The AC output ports of this system could endanger people's life, DO NOT touch the output terminal when the system is turned on. Meanwhile, non-professionals are not allowed to open the system case. Before replacing fuse, please make sure both the product main power switch and the inverter switch of front panel are all turned off, and pull out / cut off grid AC power charging cable.
Main Parts |
Specification |
Parameters |
Quantity |
Unit price
FOB SZ
(USD) |
|
solar panel |
Mono/polycrystalline |
100W |
1pcs |
USD529
MOQ50pcs
Sample price:
USD559 |
|
battery |
sealed lead-acid |
100AH |
1pcs |
|
solar control system |
controller |
15A |
1pcs |
|
Inverter |
Pure Sine Wave |
300W |
1pcs |
|
|
control box |
|
1pcs |
|
Output ports |
AC 100~220V |
|
3pc |
|
DC 12V |
12V/10A |
1pc |
|
Input ports |
AC 110/220V 3A |
|
1pc |
|
Solar panle input port |
|
1pc |
|
External battery input port |
|
1pc |
|
PRODUCT SIZE(CM) |
530× 263× 585mm, 59KG |
|
Packing(CM) |
1PC/Carton |
|
Wooden case: add 50USD |
|
With Pull Universal wheels |
Free |
|
N. W/G. W(KG/SET) |
63KG/66KG (including the solar panel) |
|
|
Specification |
Volume |
Weight |
Remarks |
|
Solar panel |
100W/18V |
1200*800*35mm9(L*W*T) |
13.5(kg) |
Without connecting
cable |
|
Control box |
100Ah/12V Lead acid battery300W
inverter |
460*230*390mm |
38.59(kg) |
(L*W*H) |
|
DC lamp & cable set |
E27 lamp holder |
Cable length: 3m |
0.07(kg) |
Jack: 5.5/2.0mm,
optional |
|
1W LED bulb |
Output power: 1.0W |
47*80 |
0.02(kg) |
DC12V'
diameter*height |
|
3W LED bulb |
Output power: 3.0W |
60*105 |
0.04(9kg) |
DC12V,
diameter*height |
|
Solar panel carton |
350 grey card framed B3 core wire
or strengthmember |
1210*810*45mm |
14.5(kg) |
|
|
Control box carton |
350 grey card framed B3 core wire
or strength member |
520*290*450mm |
48.5(kg) |
|
Shenzhen Lonfours Technology Co. Ltd is a High-tech company which engaged in the R&D, manufacture, sale of solar powered product, LED illuminating product, vehicle-bone digital device and etc. As a new-born company which established in the early year of 2010, Lonfours hold a registered capital of 1 million CNY and focus in exporting all of its product to foreign countries, it located in the most economically prosperous city in the Pearl River Delta economic area_Nanshan District, Shenzhen. Adjacent to the biggest high-tech park in the city, Lonfours share the advantage of perfect auxiliary industrial chain and R&D cluster.
Shenzhen Lonfours Technology Co, . Ltd is a professional exporter of milliwatt solar power system, solar powered water heater, solar power charger which focus in the integration and export for solar power system, solar power water heater, solar power charger, LED illuminating product, digital product and vehicle-bone product. We have an abundant of loyal customers from USA, Europe and Africa, and we are able to provide you with the satisfactory service and product.
