Air Source
Power supply
input 220V/50Hz Ozone concentration 16-22 mg/L
Work Voltage 4-5KV Inlet Flow 45-65m3/hkgO3
Work Frequency 1000-3000Hz Power consumption 18-20Kw/kgO3h
Dew point -45ºC Flow of cooling water 3.5-5T/hkgO3
Temperature of inlet 20ºC Temperature of cooling water Below 30ºCWork pressure 0.05-0.1MPa Temperature rise 4-6ºC
Type Ozone output g/h Volume( mm ) Interface caliber
CF-G-3-2.5g 2.5 320*190*400 Rc1/8
500*350*1000 Rc1/4
CF-G-3-5g 5 320*190*400 Rc1/8
500*350*1000 Rc1/4
CF-G-3-10g 10 500*350*1000 Rc1/4
CF-G-3-20g 20 600*400*1300 Rc1/4
CF-G-3-30g 30 600*400*1300 Rc1/4
CF-G-3-40g 40 600*400*1300 Rc3/4
Oxygen Source
Power supply
input 220V/50Hz Ozone concentration 80-100 mg/L
Work Voltage 4-5KV Inlet Flow 10-13m3/hkgO3
Work Frequency 1000-3000Hz Power consumption 9-10Kw/kgO3h
Dew point -45 ºC Flow of cooling water 2-2.5T/hkgO3
Temperature of inlet 20 ºC Temperature of cooling water Below 30ºC
Work pressure 0.05-0.1MPa Temperature rise 4-6ºC
Type Ozone output g/h Volume( mm ) Interface caliber
CF-G-3-5g 5 320*190*400 Rc1/8
CF-G-3-10g 10 320*190*400 Rc1/8
CF-G-3-20g 20 500*350*1000 Rc1/4
CF-G-3-40g 40 600*400*1300 Rc1/4
CF-G-3-60g 60 600*400*1300 Rc1/4
CF-G-3-80g 80 600*400*1300 Rc1/4
Qingdao guolin industry Co., Ltd. is an ozone product manufacturer with the most advanced ozone technology in China. The headquarters is in qingdao, China.
Qingdao guolin industry Co., Ltd. Are mainly engaged in the design of ozone project, manufacturing, installation, debugging and maintenance of ozone equipments. The company can ensure the advanced technology and reliable operation of ozone equipments which are sold in the Chinese market by relying on technical advantages of qingdao research center of ozone applied engineering technology. Qingdao guolin ozone equipment Co., Ltd. Assures its patron of products with high quality and the best after-sale service with over ten years experiences in manufacturing and operation of ozone generator.
Qingdao guolin industry Co., Ltd. has production base covering 13, 000 square meters. We produce the dta tubular dielectric, ozone generation device, high voltage transformer and install power supply system in this production base. After that, the ozone generators will be tested and debugged. Then the machines will be handed over to customers after 72-hour normal operation. According to different demands of customers, we can design and produce ozone generators with different types from 10g/h to 50kg/h. The company can produce over 500 sets of equipments every year.
Our ozone products have been applied to the fields of running water treatment, sewage treatment, industrial oxidation, disinfection of swimming pool, papermaking and laminating, waste gas treatment and space disinfection and so on. Many products of our company have been exported to many countries, such as Turkey, Indonesia, Brazil, Italy, Syria, Iran, India, Australia, Sudan, Israel, Ghana and so on.
